Multibrackets M Ceiling Mount Pro MBC5X1UP VESA 200
Multibrackets M Ceiling Mount Pro MBC5X1UP VESA 200, 150 kg, 68.6 cm (27"), 81.3 cm (32"), 75 x 75 mm, 200 x 200 mm, 0 - 15°
Availability:: Arriving soon
The M Ceilingmount Pro MBC5X1UP VESA 200 is our 5 screen side by side menuboard system - ready to be installed.The professional Pro Series A/V line from Multibrackets was designed with the installer in mind. Modular, easy to configure, quick to install and simple to maintain. Developed together with installers we added close to unlimited flexibility and versatility. Based on the Pro Series ultra-flexible aluminum rail it is completely modular and has built in cable management throughout the entire solution to quicken installation and create an esthetic result worth the public eye.With its modular construction installers can tailor with the clients need in mind. Possibilities to change, update and reconfigure its design and if ideas change over time Pro Series can follow.The M Ceilingmount Pro MBC5X1UP VESA 200 creates a seamless mounting surface through the aluminum rail. The tilted mounting of the displays allow all 5 displays to be placed side by side in portrait and tilted at the same angle with ease creating alignment and true menuboard perfection.Designed with our Scandinavian heritage in mind Pro Series provides a clean Nordic look where each part and detail is made as simple as can be and still service its function. Possible to use in a variety of environments our Pro Series Menuboards are truly versatile. The Pro Series possibilities to extend pipes and add details by individual choice is vast so that one can tailor each mount to its location and function. With included hardware kit a basic installation should not be a hassle.Multibrackets Pro Series Menuboards is simply ideal for any large screen digital signage application.
| Mounting | |
|---|---|
| Maximum weight capacity | 150 kg |
| Minimum screen size | 27 " |
| Number of displays supported | 5 |
| Maximum weight capacity (per display) | 30 kg |
| Maximum screen size | 32 " |
| Mounting type | Ceiling |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 200 x 200 mm |
| Panel mounting interface | 75 x 75,100 x 100,100 x 200,200 x 100,200 x 200 mm |
| Ergonomics | |
| Height adjustment | Y |
| Tilt angle range | 0 - 15 ° |
| Cable management | Y |
| Ceiling mounting tube length (min) | 580 cm |
| Ceiling mounting tube length (max) | 1550 cm |
| Tilt adjustment | Y |
| Design | |
| Product colour | Black |
| Housing material | Aluminium,Steel |
| Weight & dimensions | |
| Width | 1100 mm |
| Depth | 230 mm |
| Height | 150 mm |
| Weight | 28720 g |
| Aluminium content weight | 5400 g |
| Steel content weight | 28714.6 g |
| Other metals content weight | 0 g |
| Packaging data | |
| Package width | 400 mm |
| Package depth | 1000 mm |
| Package height | 200 mm |
| Package weight | 30000 g |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Mounting kit | Y |
| Technical details | |
| Orientation | Portrait |
| Paper/cardboard packaging weight | 1200 g |
| Metal packaging weight | 0 g |
| Plastic packaging weight | 80 g |
