LG 105BM5P-B Signage Display Digital signage flat panel 2.67 m (105") Wi-Fi 440 cd/m² 5K Ultra HD Black Android 16/7
LG 105BM5P-B, Digital signage flat panel, 2.67 m (105"), 5120 x 2160 pixels, Wi-Fi, 16/7
Availability:: Arriving soon
21:9 Extended Wide FormatWith support for a 21:9 widescreen aspect ratio, 105BM5P provides an immersive viewing experience with the wider screen than 16:9 display. Its screen specialization helps display 21:9 content including widescreen videoconferencing platforms with the natural details.Portrait / Landscape ModeThe 105BM5P offers versatile usage, with the ability to be used in both vertical and horizontal orientations. This flexibility allows it to adapt to various installation and usage scenarios.High Resolution DisplayIt provides a resolution that's more than 4 times higher than FHD, making the viewer satisfied visually. With a resolution of 5,120 × 2,160 and a high pixel density, every single detail of the display screen is conveyed vividly.Slim Depth DesignThe 105BM5P stands out with its slim bezel and sleek depth design with reduced weight. Not only does it save space, but it also facilitates easy installation, making it an ideal choice for a variety of settings.Easily Connect & Charge with USB Type-CUSB Type-C connectivity simplifies connections which enables charging and sending data simultaneously over just one single cable.Wireless ScreenShareThe 105BM5P offers a wireless screen sharing feature, known as LG CreateBoard Share, allowing for easy sharing of presentation materials wirelessly, thus eliminating the clutter of wires. This enables users to show up to 9 shared screens or a file on a screen in real-time when the LG CreateBoard Share app is installed on the device. Also, files from the host can be easily sent to any devices connected to the app.OPS Slot105BM5P supports OPS slots, allowing you to conveniently mount OPS Module at the back of the screen without the hassle of connecting to an external desktop, enabling various PC functions and Windows software even on the 105BM5P.LG ConnectedCare DMSLG ConnectedCare DMS is a cloud solution for remotely monitoring, controlling, and managing the status of devices. This feature enables IT managers to manage important resources on operating devices without physically visiting sites.Remote ControlThanks to LG ConnectedCare DMS, IT manager can select specific devices to be controlled remotely and update their settings all at once. General settings, power settings, application management, and multimedia can all be effectively managed and controlled simultaneously, enabling the stable operation of clients' businesses.Broadcast / Alert MessageMessages and a range of other content can be sent from the main system's hub to individual devices connected to LG ConnectedCare DMS and you can easily display important company notices or schedules right on your device. In case of urgent occasions such as a fire or a natural disaster, alert messages can be distributed manually across the system, which helps people promptly take a safety action.
| Display | |
|---|---|
| Panel type | IPS |
| LED backlighting type | Direct-LED |
| Display diagonal | 105 " |
| Display resolution | 5120 x 2160 pixels |
| Display brightness | 440 cd/m² |
| HD type | 5K Ultra HD |
| Touchscreen | N |
| Native aspect ratio | 21:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 5000:1 |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Panel life | 50000 h |
| Colour depth | 10 bit |
| Native refresh rate | 60 Hz |
| Colour gamut | 72 % |
| Ports & interfaces | |
| HDMI ports quantity | 5 |
| HDMI version | 2.0/2.1 |
| HDMI input ports quantity | 4 |
| HDMI output ports quantity | 1 |
| DisplayPorts quantity | 1 |
| DisplayPorts in | 1 |
| USB port | Y |
| USB ports quantity | 11 |
| USB 2.0 Type-B ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| RS-232C | Y |
| Audio | |
| Built-in speaker(s) | Y |
| RMS rated power | 47 W |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Y |
| Panel mounting interface | 1000 x 600 mm |
| Bezel width (bottom) | 18 mm |
| Bezel width (side) | 18 mm |
| Bezel width (top) | 18 mm |
| Performance | |
| Purpose | Commercial |
| On Screen Display (OSD) | Y |
| Operating hours (hours/days) | 16/7 |
| HDCP | Y |
| HDCP version | 2.3 |
| Power | |
| Power consumption (typical) | 412 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 632 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Heat dissipation | 1406 BTU/h |
| Computer system | |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| Processor architecture | ARM Cortex-A76+Cortex-A55 |
| Internal memory | 64 GB |
| On-board graphics card model | ARM Mali-G610 MP4 |
| Internal storage capacity | 8 GB |
| Operating system installed | Android |
| Operating system version | 13.0 |
| Weight & dimensions | |
| Display width | 2490 mm |
| Display depth | 77 mm |
| Display height | 1074 mm |
| Display weight | 54100 g |
| Packaging data | |
| Package width | 2668 mm |
| Package depth | 1233 mm |
| Package height | 280 mm |
| Package weight | 75900 g |
| Packaging content | |
| Remote control included | Y |
| Cables included | HDMI,Power |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 1000 Mbit/s |
| Wi-Fi | Y |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) |
| Features | |
| Wall mountable | Y |
| Heat dissipation (max) | 2156 BTU/h |
| Technical details | |
| Surface treatment | 25 |
| Other features | |
| Bluetooth | Y |
| Bluetooth version | 5.2 |
| Plug and Play | Y |
