iiyama TE6513A-B1AG Signage Display Interactive flat panel 163.8 cm (64.5") Wi-Fi 500 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 18/7
iiyama TE6513A-B1AG, Interactive flat panel, 163.8 cm (64.5"), 3840 x 2160 pixels, Wi-Fi, 18/7
Availability:: Arriving soon
The TE6513A-B1AG is a cutting-edge 4K UHD Google EDLA Certified interactive display that redefines performance and precision. Featuring a Zero-Gap Air Bonding LCD screen to eliminate parallax and with PureTouch-IR+ with Palm Rejection, it ensures smooth, accurate interaction. Powered by iiWare 21E with Android 14-EDLA, WiFi-6 with Bluetooth 5.0 connectivity, iControl (DMS), iiShare and integrated EShare app (wireless screen sharing), it integrates seamlessly into your ecosystem. Enjoy added features like a PIR motion sensor for energy efficiency; perfect for workplaces and educational spaces, it fosters collaboration, communication, and progress.
| Display | |
|---|---|
| Panel type | IPS |
| Display diagonal | 64.5 |
| Display resolution | 3840 x 2160 |
| Display brightness | 500 |
| HD type | 4K Ultra HD |
| Touchscreen | Y |
| Touchscreen technology | PureTouch-IR |
| Number of simultaneous touchpoints | 40 |
| Native aspect ratio | 16:9 |
| Response time | 8 |
| Contrast ratio (typical) | 1200:1 |
| Viewing angle, horizontal | 178 |
| Viewing angle, vertical | 178 |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.372 x 0.372 |
| Active display area (W x H) | 1428.5 x 803.5 |
| Display diagonal (metric) | 163.9 |
| Horizontal scan range | 30 - 135 |
| Native refresh rate | 60 |
| Surface hardness | 7H |
| Glass thickness | 3.2 |
| Ports & interfaces | |
| HDMI ports quantity | 3 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| USB port | Y |
| USB ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| USB Power Delivery (USB PD) | Y |
| USB Power Delivery up to | 100 |
| USB Type-C DisplayPort Alternate Mode | Y |
| Ethernet LAN (RJ-45) ports | 2 |
| RS-232C | Y |
| OPS module slot | Y |
| Audio Return Channel (ARC) | Y |
| Audio | |
| Built-in speaker(s) | Y |
| Number of built-in speakers | 2 |
| RMS rated power | 60 |
| Design | |
| Product design | Interactive flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal |
| Product colour | Black |
| VESA mounting | Y |
| Panel mounting interface | 600 x 400 |
| Bezel colour | Black |
| Anti-glare screen | Y |
| Positioning accuracy | 1 |
| Performance | |
| Purpose | Education |
| On Screen Display (OSD) | Y |
| Number of OSD languages | 13 |
| On Screen Display (OSD) languages | CZE,DAN,DEU,DUT,ENG,ESP,FIN,FRE,ITA,POL,RUS,SLV |
| Operating hours (hours/days) | 18/7 |
| HDCP | Y |
| HDCP version | 2.2 |
| Mean time between failures (MTBF) | 50000 |
| Power | |
| Power consumption (typical) | 182 |
| Power consumption (standby) | 0.5 |
| Power consumption (off) | 0.3 |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 182 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Energy efficiency scale | A to G |
| Computer system | |
| Computer system | Y |
| Built-in processor | Y |
| Processor architecture | ARM Cortex-A73 |
| Processor frequency | 1.4 |
| Processor cores | 4 |
| Internal memory | 8 |
| On-board graphics card model | ARM Mali-G52 |
| Internal storage capacity | 128 |
| Operating system installed | Android |
| Operating system version | 14 |
| Weight & dimensions | |
| Display width | 1489 |
| Display depth | 87 |
| Display height | 891.5 |
| Display weight | 39400 |
| Packaging data | |
| Package width | 1640 |
| Package depth | 1640 |
| Package height | 1010 |
| Package weight | 48500 |
| Packaging content | |
| Remote control included | Y |
| Stylus pen | Y |
| Number of stylus pens | 4 |
| Cables included | HDMI,Power,USB |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 60 |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 1000 |
| Wi-Fi | Y |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Technical details | |
| OPS slot | 1 |
| Other features | |
| Quick start guide | Y |
| Power supply type | Internal |
