LevelOne Hilbert 6-Port Industrial Gigabit Smart Lite Switch, 4x RJ45, 2x SFP

€98,43

LevelOne Hilbert 6-Port Industrial Gigabit Smart Lite Switch, 4x RJ45, 2x SFP, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex

Availability: In Stock

Add to Cart

Add to wishlist

Compare

EAN:4015867236161Categories:NetworkingTags:

The LevelOne IGS-2106 Hilbert Industrial gigabit smart lite switch is a next-generation Ethernet Switch offering powerful better functionality and usability that delivers the cost-effectively business and transports Ethernet services via fiber or copper connections. IGS-2106 delivers 4 (10M/100M/1G) RJ45 ports and 2 Gigabit SFP ports. With the industrial standard DIN-rail mount, plus the clearly visible status LEDs provide simple monitoring of port link activity.. can be matched with the latest LevelOne IP Locator, the software is the easiest to use switch discovery tool, it can search all Hilbert series switches, instantly know the forgotten IP and other info. Compatible with mainstream Windows and Mac operating systems.The LevelOne IGS-2106 provides high HW performance and environment flexibility for Enterprises. IGS-2106 is ideal to deliver management simplicity, optimum user experience, and lower total cost of ownership.

Management features
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Web-based management	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	4
SFP module slots quantity	2
Fiber uplink ports quantity	2
Network
Networking standards	IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3x,IEEE 802.3z
10G support	N
Copper ethernet cabling technology	10BASE-T,100BASE-TX,1000BASE-T,1000BASE-X
Port mirroring	Y
Full duplex	Y
Half duplex	Y
Flow control support	Y
Link aggregation	Y
Broadcast storm control	Y
Rate limiting	Y
Auto MDI/MDI-X	Y
Spanning tree protocol	Y
Auto-negotiation	Y
MAC address auto-learning supported	Y
MAC address auto-aging supported	Y
VLAN support	Y
Virtual LAN features	Port-based VLAN,Tagged VLAN
Number of VLANs	32
Data transmission
Switching capacity	12
Forwarding rate	8.928
MAC address table	2000
Jumbo frames support	Y
Jumbo frames	9000
Packet buffer memory	1.5
Security
IGMP snooping	Y
Queue scheduling algorithms	Priority queuing (PQ)
Multicast features
Multicast support	Y
Design
Product colour	Black
LED indicators	Activity,Link,Power
International Protection (IP) code	IP30
DIN rail mounting	Y
Performance
Flash memory	2
Noise level	0
Fanless	Y
Mean time between failures (MTBF)	43800
Power
Power source	DC
Power supply included	N
Redundant power supply (RPS) support	Y
DC input voltage	12 - 57
Power consumption (typical)	6
Surge protection	Y
Surge protection voltage	4
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
Operational conditions
Operating temperature (T-T)	-40 - 75
Storage temperature (T-T)	-40 - 85
Operating relative humidity (H-H)	10 - 90
Storage relative humidity (H-H)	5 - 95
Heat dissipation	20.47
Weight & dimensions
Width	136
Depth	108
Height	38.5
Weight	430
Packaging content
Quick start guide	Y
Packaging data
Terminal block included	Y
Package type	Box
DIN rail included	Y
Package width	191
Package depth	135
Package height	60
Package weight	680
Sustainability
Sustainability compliance	Y
Technical details
Layers per pallet (air)	16
Pallet gross length	800
Pallet gross width	1200
Certificates
Compliance certificates	CE,Federal Communications Commission (FCC),RoHS,UKCA
Logistics data
Pallet gross height	1544
Country of origin	China
Master (outer) case width	480
Master (outer) case length	395
Master (outer) case height	350
Harmonized System (HS) code	8517620090
Master (outer) case gross weight	24000
Products per master (outer) case	34
