Lanview LVO2314005-FLEX InfiniBand/fibre optic cable 0.5 m LC LC/LC Yellow
€8,41
Lanview LVO2314005-FLEX, 0.5 m, LC/LC, OS2, LC, LC
Availability: Arriving Soon
The Lanview Bendable series is designed for flexible cable management, able to bend and hold any angle from a straight line to 90 degrees. The boot, shaped over a single stainless-steel wire, can be effortlessly positioned by hand, while the internal wire guarantees it retains the chosen angle or direction.the boot can be reshaped at any time or straightened for connector disconnect. This enables perfect installation of the connector in unique applications such as, tight constraint areas or high density environments.
| Features | |
|---|---|
| Cable length | 0.5 m |
| Fibre optic type | OS2 |
| Cable shape | Round |
| Connector 1 | LC |
| Connector 2 | LC |
| Connector 1 gender | Male connector |
| Connector 2 gender | Male connector |
| Connector polish type | UPC |
| Cable type | LC/LC |
| Product colour | Yellow |
| Full duplex | Y |
| Core diameter | 9 µm |
| Cladding diameter | 125 µm |
| Fiber mode structure | Single-mode |
| Insertion loss | 0.3 dB |
| Return loss | 50 dB |
| Compressive strength | 10 |
| Jacket material | Low smoke zero halogen (LSZH) |
| Plug and Play | Y |
| Sustainability | |
| Doesn't contain | Halogen |
| Certificates | |
| Compliance certificates | REACH,RoHS |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Weight & dimensions | |
| Cable diameter | 2 mm |
| Weight | 10 g |
| Bending radius | 30 mm |
| Packaging data | |
| Package width | 180 mm |
| Package depth | 40 mm |
| Package height | 200 mm |
| Package weight | 10 g |
| Logistics data | |
| Warranty period | 25 year(s) |
