ATEN 4-Port USB 2.0 Extender Over LAN
ATEN 4-Port USB 2.0 Extender Over LAN, Network transmitter & receiver, 100 m, 480 Mbit/s, Cat5, Cat6, Cat7, 10,100,1000 Mbit/s, Black
Availability: In Stock
The UEH4102 4-port USB 2.0 Extender over LAN incorporates patented ExtremeUSB® technology that enables users to extend beyond the standard 5 meter cable limit for USB peripheral devices.1x UEH4102L 4-Port USB 2.0 Cat 5 Extender over LAN (Local unit)1x UEH4102R 4-Port USB 2.0 Cat 5 Extender over LAN (Remote unit)1x 0AD9-1B05-30EG Power Adapter1x LIN6-04U1-V1BG USB 2.0 Type-A to Type-B Cable1x User Instructions
| Performance | |
|---|---|
| Type | Network transmitter & receiver |
| Maximum transfer distance | 100 m |
| Data transfer rate | 480 Mbit/s |
| Cable types supported | Cat5,Cat6,Cat7 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Windows operating systems supported | Y |
| Mac compatibility | Y |
| Linux operating systems supported | Y |
| Ports & interfaces | |
| RJ-45 ports quantity (transmitter) | 1 |
| RJ-45 ports quantity (receiver) | 1 |
| USB 2.0 ports quantity | 5 |
| DC-in jack | Y |
| Design | |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Power | |
| Power consumption (receiver) (max) | 15 W |
| External power adapter | Y |
| Output voltage | 5 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Storage relative humidity (H-H) | 0 - 80 % |
| Weight & dimensions | |
| Width | 76 mm |
| Depth | 100 mm |
| Height | 26 mm |
| Weight | 540 g |
| Packaging content | |
| Cables included | USB |
| Manual | Y |
| AC adapter included | Y |
| Packaging data | |
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 160 mm |
| Package weight | 754 g |
| Logistics data | |
| Master (outer) case net weight | 2700 g |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 250 mm |
| Master (outer) case length | 325 mm |
| Master (outer) case height | 175 mm |
| Master (outer) case gross weight | 4220 g |
| Products per master (outer) case | 5 pc(s) |
