ATEN 2-Port USB 3.0 4K HDMI Dual Display KVMP™ Switch
€532,85
ATEN 2-Port USB 3.0 4K HDMI Dual Display KVMP™ Switch, 4096 x 2160 pixels, 4K Ultra HD, 3.17 W, Black
Availability: Arriving Soon
1x CS1842 2-Port USB 3.0 4K HDMI Dual Display KVMP™ Switch4x LIN6-19V1-V18G HDMI 2.0 Cables 2x LIN6-11C1-E12G USB 3.0 Cables2x LIN5-0205-21CG Speaker Cables2x LIN5-0205-21DG Microphone Cables 1x 0AD8-8012-33MG Power Adapter1x 2XRT-0016G Remote Port Selector1x User Instructions
| Ports & interfaces | |
|---|---|
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI |
| HDMI ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 2 |
| Console ports | 3.5mm headphone,HDMI,USB A |
| Console USB ports quantity | 2 |
| USB hub | Y |
| USB 2.0 Type-A hub ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 2 |
| USB connector type | USB Type-A,USB Type-B |
| Audio connections | Y |
| Headphone outputs | 4 |
| Number of microphone inputs | 4 |
| DC-in jack | Y |
| Performance | |
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 pixels |
| Video bandwidth | 60 Hz |
| Scan interval | 1,5,99 s |
| Design | |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Push button | Y |
| Hot keys | Y |
| Display | |
| Built-in display | N |
| Power | |
| Power source | DC |
| Input voltage | 12 V |
| Power consumption (typical) | 3.17 W |
| System requirements | |
| Windows operating systems supported | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Storage relative humidity (H-H) | 0 - 80 % |
| Weight & dimensions | |
| Width | 335 mm |
| Depth | 160.5 mm |
| Height | 44 mm |
| Weight | 2750 g |
| Packaging data | |
| Package width | 116 mm |
| Package depth | 540 mm |
| Package height | 233 mm |
| Package weight | 3522 g |
| Packaging content | |
| Quick installation guide | Y |
| Manual | Y |
| Logistics data | |
| Master (outer) case net weight | 8250 g |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 375 mm |
| Master (outer) case length | 565 mm |
| Master (outer) case height | 258 mm |
| Master (outer) case gross weight | 11494 g |
| Products per master (outer) case | 3 pc(s) |
