ATEN HDMI HDBaseT Receiver with POH
ATEN HDMI HDBaseT Receiver with POH, 4096 x 2160 pixels, AV receiver, 150 m, Wired, 3D, HDCP
Availability:: Arriving soon
The VE1812R features Power over HDBaseT (POH) which sends power from Tx to Rx over Cat 5e / 6 / 6a cable without any additional power supply. The VE1812R supports RS-232 and IR signaling pass-through, allowing you to control the HDMI source device from the receiver unit (VE1812R) while also accessing the HDMI display device from the transmitter unit (VE1812T). The IR signals can also be extended in both directions.1x VE1812R HDMI HDBaseT Receiver with POH1x 0AD9-1F05-26EG Power Adapter1x RS-232 Terminal Block1x User Instructions
| Features | |
|---|---|
| Type | AV receiver |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e,Cat6,Cat6a |
| Maximum transfer distance | 150 m |
| LED indicators | Y |
| Supported video modes | 1080p,2160p |
| Supported graphics resolutions | 3840 x 2160,4096 x 2160 |
| Bandwidth | 340 MHz |
| HDCP | Y |
| Material | Metal |
| 3D | Y |
| Consumer Electronics Control (CEC) support | Y |
| Impedance | 100 Ω |
| Product colour | Black |
| Ports & interfaces | |
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| HDBaseT port | Y |
| Number of HDMI outputs | 1 |
| RS-232 output ports | 1 |
| Video out | 1 |
| 3.5 mm (1/8-inch) out | Y |
| Remote (IR) output | 1 |
| DC-in jack | Y |
| Power | |
| Operating voltage (receiver) | 5 V |
| Power consumption (receiver) (max) | 6.4 W |
| External power adapter | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Weight & dimensions | |
| Weight | 650 g |
| Receiver dimensions (WxDxH) | 123 x 140.4 x 30 mm |
| Receiver weight | 450 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 160 mm |
| Package weight | 750 g |
| Packaging content | |
| AC adapter included | Y |
| Quick start guide | Y |
| Technical details | |
| Compliance certificates | RoHS |
| Logistics data | |
| Master (outer) case width | 250 mm |
| Master (outer) case length | 325 mm |
| Master (outer) case height | 175 mm |
| Master (outer) case gross weight | 4480 g |
| Master (outer) case net weight | 3250 g |
| Products per master (outer) case | 5 pc(s) |
