Vaddio ConferenceSHOT 10 2.38 MP White CMOS 25.4 / 2.8 mm (1 / 2.8")

(0 review)Add your review

€1542,47

Vaddio ConferenceSHOT 10, 2.38 MP, CMOS, 10x, White

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:840077504823Categories:AV Equipment

- 10XOptical Zoom Lens- Exmor 1/2.8-Type 2.14 Effective Megapixels (Native 1080p/60) high-speed, low noise CMOS image sensor- Built-in web server for configuration, control and remote managementThe Vaddio™ ConferenceSHOT 10 Camera is an Enterprise-Class, high definition PTZ conferencing camera with high quality imaging, exceptional color reproduction and truly fine detail. With simultaneous and individual USB 3.0 uncompressed and IP (H.264) streaming video outputs, this camera offers integrators, dealers and end users with an impressive improvement over other USB conferencing cameras available today.The latest generation Exmor™ 1/2.8”, 2.38 Megapixel, Full HD (native 1080p/60) high-speed, low noise CMOS image sensor combined with the new ISP, produces vivid and realistic color with super-fast, razor sharp and transparent auto-focus and iris routines.The ConferenceSHOT 10 USB has an Ethernet port for IP (H.264) streaming and a built-in web server, which allows the user to control the camera’s functions with an internal web page with any browser from anywhere in the world, over the IP network, while watching the RTSP format video stream with H.264 compression. With a 74-degree wide horizontal field-of-view and 10X optical zoom, the ConferenceSHOT 10 USB provides great flexibility in a variety of applications including small to medium-sized conference rooms and huddle rooms as well as corporate, healthcare, government and education environments.

Camera
Megapixel (approx.)	2.38 MP
Sensor type	CMOS
Optical sensor size	1/2.8 "
Effective sensor resolution	2.14 MP
Optical zoom	10 x
Optical zoom (super-wide mode)	11 x
Focal length range	3.8 - 38 mm
Horizontal field of view (wide)	67 °
Horizontal field of view (tele)	7.6 °
Focal length range (super-wide mode)	3.8 - 41.8 mm
Wide end viewing angle (super-wide mode)	74 °
Minimum illumination	1 lx
Tele end viewing angle (super-wide mode)	7.6 °
Signal-to-Noise Ratio (SNR)	50 dB
Aperture number of steps	16
Aperture range (F-F)	1.8 - 3.4
White balance	Auto,Manual,One push
Focus adjustment	Auto/Manual
Back Light Compensation (BLC)	Y
Gain control type	Auto/Manual
Minimum working distance (wide)	10 mm
Maximum working distance (tele)	1000 mm
Sync system	Internal
Video
Supported video modes	1080i,1080p
Design
Product colour	White
Tilt angle range	-30 - 90 °
Pan range	-165 - 165 °
Web-based management	Y
Tilt speed (min)	90 °/sec
Tilt speed (max)	90 °/sec
Pan speed (min)	90 °/sec
Pan speed (max)	90 °/sec
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity	1
Ethernet LAN (RJ-45) ports	2
DC-in jack	Y
Power
DC input voltage	12 V
Input current	3 A
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-5 - 60 °C
Operating relative humidity (H-H)	20 - 80 %
Storage relative humidity (H-H)	20 - 80 %
Packaging content
Remote control included	Y
Cables included	AC,USB
Quick start guide	Y
Control adapter	Y
Mounting kit	Y
AC adapter included	Y
Audio
Noise reduction	Y
Logistics data
Harmonized System (HS) code	85258900
Weight & dimensions
Width	155 mm
Depth	145 mm
Height	163 mm
Weight	1360 g
