IP30 L2+ SNMP Manageable
Specifications
Specifications
| Jumbo frames support | Yes |
| MAC address table | 8000 entries |
| Number of queues | 8 |
| Store-and-forward | Yes |
| Switching capacity | 26 Gbit/s |
| Throughput | 14,8 Mpps |
| Certification | FCC Part 15 Class A, CE |
| DIN rail mounting | Yes |
| Housing material | Aluminium |
| International Protection (IP) code | IP30 |
| LED indicators | Yes |
| Product colour | Blue, White |
| Rack mounting | No |
| Wall mountable | Yes |
| MIB support | RFC 1213 MIB-II, IF-MIB, MAU-MIB |
| Quality of Service (QoS) support | Yes |
| Switch layer | L3 |
| Switch type | Managed |
| Web-based management | Yes |
| Multicast features | Multicast support No |
| Multicast support | No |
| 10G support | No |
| Auto MDI/MDI-X | Yes |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Flow control support | Yes |
| Full duplex | Yes |
| Link aggregation | Yes |
| Number of VLANs | 255 |
| Port mirroring | Yes |
| VLAN support | Yes |
| Operational conditions | Operating relative humidity (H-H) 5 - 95 %Operating temperature (T-T) -40 - 75 °CStorage temperature (T-T) -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Other features | Power requirements 48VDC |
| Power requirements | 48VDC |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Console port | RJ-45 |
| Fiber optic connector | MiniGBIC |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Installed SFP+ modules quantity | 0 |
| SFP module slots quantity | 2 |
| Power | Power consumption (max) 255 WPower consumption (typical) 31,9 W |
| Power consumption (max) 255 W | Power consumption (typical) 31,9 W |
| Power consumption (max) | 255 W |
| Power consumption (typical) | 31,9 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 240 W |
| Protocols | Management protocols SSH, SSL, SNMP, Telnet |
| Management protocols | SSH, SSL, SNMP, Telnet |
| Security | Access Control List (ACL) Yes Security algorithms 802.1x RADIUS, SSH, SSL/TLS |
| Access Control List (ACL) Yes | Security algorithms 802.1x RADIUS, SSH, SSL/TLS |
| Access Control List (ACL) | Yes |
| Security algorithms | 802.1x RADIUS, SSH, SSL/TLS |
| Vendor information | Brand Name Planet Warranty 5 År |
| Brand Name Planet | Warranty 5 År |
| Brand Name | Planet |
| Warranty | 5 År |
| Kategorier | Hovedkategori Network Underkategori Wired Network Underkategori Network Switches Underkategori Network Switches |
| Hovedkategori | Network |
| Underkategori | Network Switches |
