Cisco Catalyst 9120AXE-E Wireless Access Point, Wi-Fi 6, 4x4 Dual 5GHz Radio, MU-MIMO, CleanAir with RF ASIC, PoE, External antenna, (C9120AXE-E)
The Catalyst 9120 Access Points are designed for mission-critical deployments with dual 5-GHz and integrated IoT radio. With CleanAir technology powered by Cisco RF ASIC, the C9120 access point goes beyond the Wi-Fi 6 (802.11ax) standard, providing radio-frequency excellence for high-density environments. These access points are resilient and intelligent while providing integrated security for mobile and IoT devices. Pairing with Cisco DNA, it further offers real-time analytics, quickly detect and contain security threats, and a network-wide consistency through automation and virtualisation.
Availability: In stock
The Catalyst 9120 Access Points are designed for mission-critical deployments with dual 5-GHz and integrated IoT radio. With CleanAir technology powered by Cisco RF ASIC, the C9120 access point goes beyond the Wi-Fi 6 (802.11ax) standard, providing radio-frequency excellence for high-density environments. These access points are resilient and intelligent while providing integrated security for mobile and IoT devices. Pairing with Cisco DNA, it further offers real-time analytics, quickly detect and contain security threats, and a network-wide consistency through automation and virtualisation.
Specifications
| Antenna connector type | RP-TNC |
| Antenna direction type | Omni-directional |
| Antenna features | Detachable antenna |
| Antenna gain level (max) | 6 dBi |
| Antenna type | Internal & external |
| Antennas quantity | 4 |
| Number of connectors | 2 |
| On/off switch | Yes |
| Placement | Ceiling, Floor, Table |
| Product colour | White |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Channels quantity | 29 channels |
| Ethernet LAN data rates | 100, 1000, 2500, 5000 |
| Maximum data transfer rate | 5000 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 2500 Mbit/s |
| Maximum data transfer rate (5 GHz) | 5000 Mbit/s |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at |
| Products per master (outer) case | 1 pc(s) |
| Firmware upgradeable | Yes |
| Syslog | Yes |
| Non-operating altitude | 0 - 4572 m |
| Operating altitude | 0 - 3000 m |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -20 - 50 °C |
| Storage temperature (T-T) | -39 - 70 °C |
| AC adapter included | Yes |
| Number of products included | 1 pc(s) |
| PoE adapter included | Yes |
| Quantity per pack | 1 pc(s) |
| CD manual | Yes |
| Flash memory | 1024 MB |
| Internal memory | 2048 MB |
| Ethernet LAN (RJ-45) ports | 1 |
| Internal RJ-45 ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| WAN connection | Ethernet (RJ-45), Mobile network (SIM), Wi-Fi |
| Power over Ethernet (PoE) | Yes |
| Power plug type | Type C |
| Security algorithms | AES, EAP, EAP-GTC, EAP-SIM, MSCHAPv2, TLS, TTLS, WPA, WPA2, WPA3 |
| Products per shipping (inner) case | 1 pc(s) |
| Brand Name | Cisco |
| Warranty | 1 year |
