ALLNET LTE/5G Modul Simcom SIM8202G-M2 3G/4G/LTE/5G M.2 NGFF Modem
The SIM8202X-M2 is a multi-band 5G NR/LTE-FDD/LTE-TDD/HSPA+
Availability: In stock
["The SIM8202X-M2 is a multi-band 5G NR/LTE-FDD/LTE-TDD/HSPA+", "Module that supports R15 5G NSA/SA data transmission up to 2.4Gbps. It has strong expandability with numerous interfaces such as PCIe, USB3.1, GPIO, etc. The module offers a lot of flexibility and easy integration for customer applications. The SIM8202X-M2 uses the M.2 form factor TYPE 3042-S3-B. SIM8202X-M2 AT commands are compatible with SIM7912G / SIM8200X-M2 series modules. This also minimizes customers' investments and enables a short time to market. It is designed for applications that require high throughput data communication under various radio propagation conditions. The unique combination of performance, security and flexibility makes this module ideal for many applications"]
Specifications
| Product | SIM8202G-M2 |
| Form Factor | M.2 |
| Dimensions(mm) | 42.0*30.0*2.3 |
| Frequency Bands | 5G/Sub-6G : n1,n2,n3,n5,n7,n8,n12,n20,n28,n38,n40,n41,n48,n66,n71,n77,n78,n79 LTE-FDD : B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/B32/B66/B71 LTE-TDD : B34/B38/B39/B40/B41/B42/B43/B48 LAA : B46 WCDMA : B1/B2/B3/B4/B5/B8 |
| GNSS | ? |
| Temperature | -30? ~ +70? |
| Supply Voltage(V) | 3.135 ~ 4.4 |
| Sub-6G | 2.4Gbps(DL)/500Mbps(UL) |
| LTE | 1Gbps(DL)/200Mbps(UL) |
| HSPA+ | 42Mbps (DL)/5.76Mbps(UL) |
| Protocol | TCP/IP/IPV4/IPV6/Multi-PDP/FTP/FTPS/HTTP/HTTPS/MQTTS/DNS/SSL3.0 |
| TLS | ? |
| File System | ? |
| FOTA | ? |
| Android RIL | Android 6/7/8/9 |
| USB Driver | Microsoft Windows Win7/Win8/Win10/Linux/Android |
| MBIM | Win8/Win10 |
| NDIS | Linux/Win7/Win8/Win10 |
| Firmware Upgrade | USB |
| SIM Card | 1.8V/2.95V |
| USB | ? |
| PCM | ? |
| I2C | ? |
| Diversity Receiver | ? |
| Regulatory | CCC/SRRC*/CTA*/RoHS*/REACH*/CE* |
