Techly Amplifier / Splitter HDMI Over IP Network
System of signal transmission professional who can carry an HDMI signal over long distances via a network cable Cat.5 / 6, using the conversion of the HDMI signal into a signal standard TCP / IP. Through a router or a repeater with a cascade connection, the HDMI signal can be extended indefinitely. The IDATA EXTIP-373, also allows to carry out function splitter because a transmitter can be connected to N receivers (max 253) to bring the HDMI signal to different screens depending on the user's needs. Supports all HDMI specification including full HD 1080p, Deep Color, Lip Sync and CEC; also supports all popular audio formats including high-resolution multichannel Dolby Digital Plus, LPCM 7.1, Dolby TrueHD and DTS Master Audio.
Availability: In stock
System of signal transmission professional who can carry an HDMI signal over long distances via a network cable Cat.5 / 6, using the conversion of the HDMI signal into a signal standard TCP / IP. Through a router or a repeater with a cascade connection, the HDMI signal can be extended indefinitely. The IDATA EXTIP-373, also allows to carry out function splitter because a transmitter can be connected to N receivers (max 253) to bring the HDMI signal to different screens depending on the user's needs. Supports all HDMI specification including full HD 1080p, Deep Color, Lip Sync and CEC; also supports all popular audio formats including high-resolution multichannel Dolby Digital Plus, LPCM 7.1, Dolby TrueHD and DTS Master Audio.
Specifications
| Cable types supported | Cat5e, Cat6 |
| Maximum resolution | 1920 x 1200 pixels |
| Maximum transfer distance | 120 m |
| Product colour | Black |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) |
| Supported video modes | 1080i, 1080p, 480i, 480p, 576i, 576p, 720p |
| Type | AV transmitter & receiver |
| Operating relative humidity (H-H) | 20 - 90 % |
| Operating temperature (T-T) | -10 - 60 °C |
| AC adapter included | Yes |
| Manual | Yes |
| DC-in jack | Yes |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Current | 1 A |
| Operating voltage | 5 V |
| Power consumption (typical) | 3 W |
| Brand Name | Techly |
| Warranty | 1 year |
| Receiver dimensions (WxDxH) | 58 x 110 x 26 mm |
| Receiver weight | 239 g |
| Transmitter dimensions (WxDxH) | 58 x 110 x 26 mm |
| Transmitter weight | 239 g |
