Techly ICOC HDMI2-4-050T HDMI cable 5 m HDMI Type A (Standard) Black
Techly ICOC HDMI2-4-050T, 5 m, HDMI Type A (Standard), HDMI Type A (Standard), 3D, 18 Gbit/s, Black
Availability:: Arriving soon
- Cable based on a new technology that offers the best data transmission between the HDMI™ source and HDMI™ display. The five twisted pairs offer better data transmission between devices- Triple shielding with resistant connectors for better performance able to optimize the signal with data integrity, even in installation environments subject to the worst EMS interference- ATC certified, this cable fully complies with the requirements of the worldwide HDMI™ standard. All cable materials are 100% RoHS compatible and lead free- Connections from HDMI™ 2.0 19-pin male to HDMI™ 19-pin male- High-speed, bidirectional communication up to 100 Mbps- Supports 4K * 2K / 60Hz resolution- Compliant with HDMI™ High Speed specifications- Die-cast PVC connector cover- HDMI™ Ethernet Channel: supports internet connection via HDMI™ (HEC)- Channel Audio Return: allows an HDMI™ connected to a TV with an integrated tuner to send the audio data "upstream" to a surround sound system, eliminating the need for a separate audio cable- Supports 3D: defines input / output protocols for the main 3D video formats, also for games and 3D home theater applications- Supports Ultra HD 4K resolution 4000x2000: allows video resolutions far beyond 1080p, supports new generation displays
| Features | |
|---|---|
| Cable length | 5 m |
| Connector 1 | HDMI Type A (Standard) |
| Connector 2 | HDMI Type A (Standard) |
| Connector 1 gender | Male connector |
| Connector 2 gender | Male connector |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Product colour | Black |
| HDMI version | 2.0 |
| 3D | Y |
| Supported graphics resolutions | 4096 x 2160 |
| Supported video modes | 1080i,1080p,720i,720p,480i,480p,2160i,2160p |
| Dolby technologies | Dolby Digital Plus,Dolby TrueHD,DTS-HD Master Audio |
| Audio Return Channel (ARC) | Y |
| HDMI Ethernet channel | Y |
| HDCP | Y |
| Data transfer rate | 18 Gbit/s |
| Data transfer rate per channel (max) | 6 Gbit/s |
| Supported digital audio channels (uncompressed) | 32 |
| Bandwidth | 600 MHz |
| AWG wire size | 30 |
| Connector contacts plating | Gold |
| Connector housing material | Polyvinyl chloride (PVC) |
| Cable type | Round cable |
| Magnetically shielded | Y |
| Shield material | Aluminium |
| Number of shielding layers | 2 |
| x.v.Color support | Y |
| Cable shielding | Aluminum mylar foil |
| Plug and Play | Y |
| Colour sampling | 4:2:0 |
| Certificates | |
| Compliance certificates | CE,RoHS,REACH |
| Certification | CE, RoHS, Reach |
| Weight & dimensions | |
| Cable diameter | 6 mm |
| Weight | 225 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Supplier features | |
| Vendor code | 109658 |
| Logistics data | |
| Warranty period | 1 year(s) |
