APC MGE Galaxy 3500 10kVA 400V with 2 Battery Modules uninterruptible power supply (UPS) 8000 W
APC MGE Galaxy 3500 10kVA 400V with 2 Battery Modules, 10 kVA, 8000 W, 40/70 Hz, 14 A, 43.3 dB, Sealed Lead Acid (VRLA)
Availability: Arriving Soon
APC MGE Galaxy 3500, 8000 Watts / 10 kVA,Input 400V 3PH / Output 400V 3PH, Extended runtime model.Includes: Battery modules ship installed, Bolt down brackets, CD with software, Installation guide, Network Management Card, Power modules ship installed, Smart UPS signalling RS-232 cable, Start-Up Service, User Manual.Availability- Dual mains input: Increases availability by allowing the UPS to be connected to two separatepower sources- Scalable runtime: Allows additional runtime to be quickly added as needed- Hot-swappable batteries: Ensure clean, uninterrupted power to protected equipment whilebatteries are being replaced- Generator compatible: Ensure clean, uninterrupted power to protected equipment when generator power is used- Automatic internal static bypass: Supplies utility power to the connected loads in the event of aUPS overload condition or fault- Battery modules connected in parallel: Delivers higher availability through redundant batteriesServiceability- Batteries that can be replaced by qualified personnel: Increases availability by allowing qualifiedpersonnel to perform upgrades and replacement of the batteries reducing the Mean Time ToRepair (MTTR)- Automatic self-test: Periodic battery self-test ensures early detection of a battery that needs to be replaced- Shippable with modules installed: Enables pre-installation UPS staging and testing and fasterinstallation- Modular design: Provides fast serviceability and reduced maintenance requirements via selfdiagnosing, field-replaceable modulesManageability- Network manageable: Provides remote management of the UPS over the network- InfraStruXure Central Compatible: Enables centralized management via InfraStruXure Central- LCD: Alphanumeric display which displays system parameters and alarms- Audible alarms: Provides notification of changing utility power and UPS conditions- Programmable frequency: Ensures compatibility with different input frequencies- LED status indicators: Quickly understand unit and power status with visual indicators- SmartSlot: Customize UPS capabilities with managements cardsTotal Cost of Ownership- Input power factor correction: Minimizes installation costs by enabling the use of smallergenerators and cabling- Temperature-compensated battery charging: Prolongs battery life by regulating the charge voltage according to battery temperature- Manual maintenance bypass: Reduces installation costs by eliminating the need for an externalmechanical bypass- Intelligent battery management: Maximizes battery performance, life, and reliability throughintelligent, precision chargingProtection- Frequency and voltage regulation: Gives higher application availability by correcting poorfrequency and voltage conditions without using the battery- Safety-agency approved: Ensures the product has been tested and approved to work safely withthe connected service provider equipment and within the specified environment. UL, FCC, CE,C-Tick approvals- Cold-start capable: Provides temporary battery power when the utility power is out
| Features | |
|---|---|
| Output power capacity | 10 |
| Output power | 8000 |
| Input frequency | 40/70 |
| Maximum current | 14 |
| Emergency Power Off (EPO) | Y |
| Noise level | 43.3 |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 5 |
| Design | |
| Product colour | Black |
| LED indicators | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -15 - 45 |
| Operating relative humidity (H-H) | 0 - 95 |
| Storage relative humidity (H-H) | 0 - 95 |
| Operating altitude | 0 - 999.9 |
| Non-operating altitude | 0 - 15000 |
| Certificates | |
| Certification | CE,EN 50091-2,EN/IEC 62040-3,EN/IEC 62040-1-1,IEC 61000-3-2,IEC 61000-3-3,ISO 14001,ISO 9001,VFI-SS-111 |
| Weight & dimensions | |
| Weight | 443000 |
| Packaging data | |
| Package weight | 474000 |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Other features | |
| Battery type | VRLA |
| Output connections | 1 x 4-wire (3PH + G) 1 x 5-wire (3PH + N + G) 1 x Screw Terminals |
| Input connection type | 5-wire (3PH + N + G) |
| Dimensions (WxDxH) | 523 x 838 x 1491 |
| Output voltage note | +/- 5% |
| Package dimensions (WxDxH) | 650 x 1062 x 1643 |
