LevelOne 24V DC Industrial Power Supply, 120W, DIN-Rail,-20 ~ +70 ℃
LevelOne 24V DC Industrial Power Supply, 120W, DIN-Rail,-20 ~ +70 ℃, 120 W, 90 -264 V, 47 - 63 Hz, 2.25 A, 16 ms, Overload, Over voltage, Short circuit
Availability: Arriving Soon
The POW-2442 should be able to accept a wide range of input voltages, typically from 90V AC to 264V AC, allowing it to operate in various industrial environments.DIN-rail Mounting to fit standard DIN-rail mounting systems commonly used in industrial cabinets, allowing for easy installation and space-saving.It's essential for the power supply to have high energy efficiency, reducing power losses and operating costs while minimizing heat generation.
| Power | |
|---|---|
| Total power | 120 |
| AC input voltage | 90 -264 |
| AC input frequency | 47 - 63 |
| Input current | 2.25 |
| Hold time | 16 |
| Power protection features | Overload,Over voltage,Short circuit |
| Performance | |
| Mean time between failures (MTBF) | 2636800 |
| Design | |
| Product colour | Blue,Silver |
| Number of fans | 0 |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 70 |
| Operating relative humidity (H-H) | 0 - 90 |
| Safety regulation & standards | |
| Safety | EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2) MTBF:2636.8K hrs min. Telcordia SR-332 (Bellcore) |
| Weight & dimensions | |
| Width | 40 |
| Depth | 113.5 |
| Height | 125.2 |
| Weight | 530 |
| Packaging data | |
| Package width | 60 |
| Package depth | 140 |
| Package height | 143 |
| Package weight | 700 |
| Package type | Box |
| Logistics data | |
| Master (outer) cases per pallet | 20 |
| Master (outer) case width | 310 |
| Master (outer) case length | 310 |
| Master (outer) case height | 305 |
| Master (outer) case gross weight | 14000 |
| Harmonized System (HS) code | 8504403090 |
| Country of origin | China |
| Other features | |
| Voltage tolerance | 1 |
| Output voltage note | 24V |
| Maximum current | 5 |
