€49,67

Lanview MO-AT-SP10BD20-12, Fiber optic, 10000 Mbit/s, SFP+, LC, 9/125 µm, BX

EAN:5715063224113Categories:NetworkingTags:

Micro-Optics products provide seamless connectivity for all your current and future network hardware needs.

Performance
SFP transceiver type	Fiber optic
Maximum data transfer rate	10000 Mbit/s
Interface type	SFP+
Single-mode fiber (SMF) supported	Y
Multi-mode fiber (MMF) supported	N
Fiber optic connector	LC
Fiber cable diameters supported (core/cladding)	9/125 µm
SFP transceiver standard	BX
Maximum transfer distance	20000 m
Wavelength	1270 nm
Tx wavelength (min)	1330 nm
Rx wavelength (min)	1270 nm
Copper ethernet cabling technology	10GBASE
Auto MDI/MDI-X	Y
Digital Diagnostics Monitoring (DDM)	Y
Features
Product colour	Silver
Form factor	SFP+
Plug and Play	Y
Hot-Plug support	Y
Easy to install	Y
Brand compatibility	Allied Telesis
Compatible products	AT-SP10BD20-12
Certificates
Compliance certificates	RoHS
Certification	MSA
Sustainability
Sustainability compliance	Y
Operational conditions
Minimum operating temperature	0 °C
Maximum operating temperature	70 °C
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Storage relative humidity (H-H)	10 - 85 %
Weight & dimensions
Width	13.4 mm
Depth	56.5 mm
Height	8.5 mm
Weight	10 g
Packaging content
Quantity per pack	1 pc(s)
Packaging data
Package width	60 mm
Package depth	100 mm
Package height	30 mm
Package weight	20 g
