Lindy 47630 networking cable Grey 0.3 m Cat6a S/FTP (S-STP)
(0 review)Add your review
€1,45

Lindy 47630, 0.3 m, Cat6a, S/FTP (S-STP), RJ-45, RJ-45, Grey

Availability: Arriving Soon
EAN:4002888476300Categories:NetworkingTags:

Cat.6A S/FTP network cable with support for bandwidth up to 500MHz and features a snagless design with gold plated contacts for ethernet standards up to 10 GBase-T. The TPE Jacket is a non-toxic alternative to PVC allowing it to be used in a variety of environments, as well as being more flexible than its counterpart with a flex rating of 10 million it has high impact and tear resistance making it a very durable jacket material.Cat.6A cable, shielded with braid as overall shield and foil shield for the individual wire pairs (S/FTP). Cat.6A cables meet the requirements of 10 Gigabit Ethernet (10GBaseT) with an operating frequency of up to 500MHz. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.The TPE used as a sheath material provides increased flexibility and easy handling of cablesAvailable lengths: 0.3m, 0.5m, 1m, 1.5m, 2m, 3m, 5m, 7.5m, 10m, 15m, 20m, 30m.

Features
Product colourGrey
Cable length0.3
Cable standardCat6a
Cable shieldingS/FTP (S-STP)
Connector 1RJ-45
Connector 2RJ-45
Connector 1 genderMale connector
Connector 2 genderMale connector
Connector 1 form factorStraight
Connector 2 form factorStraight
Connector contacts platingNickel/Gold
Connector shieldingY
Connector shield materialAluminium
Jacket materialThermoplastic Elastomer (TPE)
Cable shapeRound
Conductor materialCopper
Connector housing materialPolycarbonate (PC)
Cabling technology10GBase-T
AWG wire size28
Frequency500
Bend radius (min)74
Snagless cable bootY
Plug and PlayY
Operational conditions
Operating temperature (T-T)-10 - 60
Storage temperature (T-T)-20 - 75
Certificates
Compliance certificatesREACH,RoHS
CertificationRoHS, REACH, California Proposition 65
Weight & dimensions
Width11.6
Depth22.8
Height8.3
Outer diameter6.2
Connector 1 dimensions (WxDxH)11.6 x 22.8 x 8.3
Connector 2 dimensions (WxDxH)11.6 x 22.8 x 8.3
Packaging content
Quantity per pack1
Packaging data
Package typePolybag
Logistics data
Warranty period10
Technical details
Sustainability complianceY
