ATEN 2-Port 4K DisplayPort Dual Display Mini-Matrix Boundless KVM Switch
ATEN 2-Port 4K DisplayPort Dual Display Mini-Matrix Boundless KVM Switch, 4096 x 2160 pixels, 4K Ultra HD, 11.58 W, Black
Availability: Arriving Soon
With hybrid working evolving to become the standard in the new normal, the key to tackling challenges is to elevate multitasking abilities. When it comes to performing multiple tasks simultaneously, ergonomics is what assures productivity. And when communicating with dispersed remote teams, effective collaboration tools are crucial. Re-imagine your workspace with the CM1942 – a future-proof mini matrix KVM switch featuring flexible and boundless KVM switching between two computers/displays to maximize workstation efficiency. Incorporating speedy peripheral data sharing, audio mixer, multi-screen efficiency and hotdesking agility, the CM1942 promotes a productive yet better normal with streamlined desktop workflows for both desktop tasks and collaborative work.Exceptional 4K Audiovisual PerformanceThe CM1942 empowers your desktop operations with connectivity to two DisplayPort computers and two HDMI displays, providing a remarkable user experience with exceptional 4K audiovisual enhancement.Dual-Display Setting to Facilitate Matrix KVM SwitchingThe CM1942's dual-display setting simplifies KVM switching in a 2x2 computer/monitor matrix. The main and extended desktops of either computer with the current KVM focus can be displayed over two monitors. Likewise, each computer’s content can be displayed on either monitor separately in a crossover configuration as well, regardless of the KVM focus.Intuitive Boundless Switching to Expedite Desktop OperationsThe CM1942 enables quick switching between two computers by allowing the mouse cursor to move across the screen borders onto another screen instantaneously, for easy and straightforward switching between sources.Audio Mixer Mode to Enhance Situational AwarenessSound can serve as a helpful alert for better situational awareness while multitasking. With the Audio Mixer mode in place, the audio and sound coming from both computers can be mixed up in one output during all desktop operation, regardless whichever computer you’re working on at the moment.Flexible Port SelectionPort switching with the CM1942 is flexible and you can choose from pushbuttons, hotkeys, mouse and the remote port selector, whichever works best for you and your workflows.Peripheral SharingMedia and data sharing between computers is fast and effortless via plug-n-play connection (e.g. hard drive, flash drive, printer, etc) to the USB hub on the KVM switch.ApplicationsThe compact CM1942 is best suited to multitasking operations in any desktop workspace setting where streamlined workflows and collaborations are pursued.
| Ports & interfaces | |
|---|---|
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DisplayPorts quantity | 4 |
| DisplayPort version | 1.2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 2 |
| Console ports | 3.5mm headphone,3.5mm mic,HDMI,USB A |
| Console HDMI ports quantity | 2 |
| USB hub | Y |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 2 |
| Audio connections | Y |
| Headphone outputs | 4 |
| Number of microphone inputs | 4 |
| DC-in jack | Y |
| Performance | |
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 |
| Data transfer rate (max) | 5 |
| Scan interval | 1,3,4,5,8,10,15,20,25,30,35,40,45,50,55,60,70,80,90,99 |
| HDCP | Y |
| Power on detection | Y |
| Design | |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Push button | Y |
| Hot keys | Y |
| Display | |
| Built-in display | N |
| Power | |
| Power source | DC |
| Power consumption (typical) | 11.58 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 60 |
| Operating relative humidity (H-H) | 0 - 80 |
| Weight & dimensions | |
| Width | 71.8 |
| Depth | 260 |
| Height | 42.5 |
| Weight | 640 |
| Packaging data | |
| Package width | 98 |
| Package depth | 325 |
| Package height | 210 |
| Package volume | 6796.04 |
| Package weight | 1900 |
| Logistics data | |
| Master (outer) case net weight | 8100 |
| Master (outer) case width | 342 |
| Master (outer) case length | 512 |
| Master (outer) case height | 232 |
| Master (outer) case gross weight | 10160 |
| Master (outer) case volume | 40776.25 |
| Country of origin | Taiwan |
