ATEN 8-Port 19" LCD KVM Switch (USB - PS/2 VGA) with USB Peripheral port (Dual Rail)
(0 review)Add your review
€1616,55

ATEN 8-Port 19" LCD KVM Switch (USB - PS/2 VGA) with USB Peripheral port (Dual Rail), 48.3 cm (19"), 1280 x 1024 pixels, LCD, 250 cd/m², 1000:1, 170°

Availability: Arriving Soon
EAN:4710469345555Categories:Servers & StorageTags:

The CL5808 Slideaway™ Dual Rail LCD KVM Switch is a control unit that allows access to multiple computers from two PS/2 or USB KVM consoles. An extra console port is provided on the rear panel to manage the LCD KVM switch from an optional external consoles.The CL5808 19" LED-backlit LCD monitor and keyboard/touch pad modules slide independently of each other. To maximize space in your data center, the keyboard/touch pad module slides back to "hide away" when not in use, while the thin profile LCD monitor rotates back - flush against the rack - allowing convenient monitoring of computer activity. Quickly and conveniently switch computer access with station and port selection pushbutton switches located on the keyboard module. Even when the keyboard module is in the retracted position you can still switch access with the Port Up/Port Down pushbuttons located on the monitor module.The CL5808 supports both PS/2 and USB keyboards and mice for the connected computers, and the CL5808 supports USB peripheral devices to be used with the attached computers. A single CL5808 can control up to 8 computers. As many as 31 additional compatible KVM switches can be daisy chained together, so that up to 256 computers can all be controlled from a single keyboard, monitor, and mouse console.Note: Optional rack mount kits are available. For more information, refer to Compatible Accessories below.

Display
Display diagonal19
Display resolution1280 x 1024
DisplayLCD
Display brightness250
Contrast ratio (typical)1000:1
Viewing angle, horizontal170
Viewing angle, vertical160
On Screen Display (OSD)Y
Pixel pitch0.294 x 0.294
Display typeTFT
Response time5
Supported resolutions1280 x 1024 @75 Hz; DDC2B, 1920 x 1200 @ 60 Hz
Technical details
MaterialMetal,Plastic
Product colourBlack
Hot-Plug supportY
Operating relative humidity (H-H)0 - 80
Built-in KVM switchY
KVM switch ports quantity8
Maximum resolution1920 x 1200
Rack mountingY
Console portSPHD-18
Daisy chainY
Number of computers controlled256
On/off switchY
LED indicatorsY
Push buttonY
Auto scan delay (min)1
Auto scan delay (max)255
Compliance certificatesRoHS
Rack capacity1U
Ports & interfaces
VGA (D-Sub) ports quantity1
I/O ports1x RJ-11 1x DB-25 8x SPHD-17/18
Keyboard port typeUSB
Mouse port typeUSB
Video port typeVGA
USB 2.0 Type-A ports quantity3
Keyboard
Built-in touchpadY
Keyboard languageUS English
Keyboard layoutQWERTY
Hot keysY
Power
Power consumption (typical)25
AC adapter input voltage100 - 240
AC adapter frequency50/60
Input current1
AC (power) inY
Operational conditions
Operating temperature (T-T)0 - 50
Storage temperature (T-T)-20 - 60
System requirements
Windows operating systems supportedY
Mac operating systems supportedY
Linux operating systems supportedY
Weight & dimensions
Width680.4
Height44
Depth480
Weight14480
Packaging data
Package weight18620
Package width668
Package depth833
Package height135
Packaging content
Cables includedAC,KVM
Quick installation guideY
ManualY
Rack mount kitY
Logistics data
Master (outer) case net weight15400
Master (outer) case width668
Master (outer) case length833
Master (outer) case height135
Master (outer) case gross weight18620
Products per master (outer) case1
