Aerocool LUX 550W power supply unit 20+4 pin ATX ATX Black
Aerocool LUX 550W, 550 W, 220 - 240 V, 50 - 60 Hz, 4 A, Active, 100 W
Availability: Arriving Soon
Up To 88%+ Efficiency80Plus 230V EU Bronze Certified for high efficiency performance.Stylish, Elegant DesignFeaturing a stylish, elegant design, the LUX PSU is the perfect balance between power and luxury.This power supply elevates the look and feel of your rig while delivering maximum efficiency power.Improved Air Ventilation30% Increased ventilation area in the body of the PSU allows for increased air flow and circulation, preventing your system from overheating.Optimized Fan RPM12cm silent black fan with optimized thermal fan speed control. Fan runs at startup speed (less than 800RPM) before reaching 60% load at 25℃ ambient temperaturesConvenient Cable Management Soft, black, flat cables allow for more convenient cable management and easier installation.CompatibilityCompatible with all Intel form factors up to ATX12V Ver.2.4.
| Power | |
|---|---|
| Total power | 550 |
| AC input voltage | 220 - 240 |
| AC input frequency | 50 - 60 |
| Input current | 4 |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 100 |
| Combined power (+12V) | 504 |
| Combined power (+5V) | 100 |
| Combined power (-12V) | 3.6 |
| Combined power (+5Vsb) | 12.5 |
| Max output current (+3.3V) | 20 |
| Max output current (+12V) | 42 |
| Max output current (+5V) | 20 |
| Max output current (-12V) | 0.3 |
| Max output current (+5Vsb) | 2.5 |
| Efficiency | 88 |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 500 |
| Number of SATA power connectors | 4 |
| Number of PATA power connectors | 2 |
| SATA power cable length | 550 |
| PCI Express power connectors (6+2 pin) | 1 |
| PCI Express power cable length | 450 |
| CPU power connector (4+4 pin) | Y |
| CPU power cable length | 550 |
| ATX power connector (20+4 pin) | Y |
| PCI Express connector | Y |
| Cabling type | Non-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Bronze |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 2.4 |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 120 |
| Number of fans | 1 |
| Packaging content | |
| Cables included | AC |
| Packaging data | |
| Manual | Y |
| Package width | 230 |
| Package depth | 195 |
| Package height | 95 |
| Package type | Box |
| Logistics data | |
| Master (outer) case width | 250 |
| Master (outer) case length | 495 |
| Master (outer) case height | 215 |
