Shuttle PC850 power supply unit 850 W 20+4 pin ATX Flex ATX Grey
€279,41
Shuttle PC850, 850 W, 100 - 240 V, 50 - 60 Hz, Active, 3 W, 20 A
Availability: Arriving Soon
The Shuttle XPC Accessory PC850 is an internal AC to DC switching power supply unit (PSU) meant as upgrade kit for certain Shuttle products. This power supply is guaranteed to deliver an excess of power for power-hungry processors and graphics cards. It provides a maximum output wattage of 850 Watt. Its 80 PLUS® Platinum and Energy Star V5.0 compliance helps save on energy costs as compared to previous power supply models.
| Power | |
|---|---|
| Total power | 850 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+5Vsb) | 3 |
| Max output current (+3.3V) | 20 |
| Max output current (+12V) | 70.8 |
| Max output current (+5V) | 20 |
| Max output current (-12V) | 0.5 |
| Hold time | 17 |
| Efficiency | 92 |
| Power protection features | Over current,Over voltage,Overheating,Short circuit |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 4 |
| PCI Express power connectors (6+2 pin) | 2 |
| Performance | |
| 80 PLUS certification | 80 PLUS Platinum |
| Purpose | PC |
| Power supply unit (PSU) form factor | Flex ATX |
| Bearing technology | Ball bearing |
| Mean time between failures (MTBF) | 100000 |
| Compatible products | Shuttle XPC Cubes SH510R4, SH570R6 Plus, SH570R6 Plus, SH570R8, SW580R8 |
| Design | |
| Product colour | Grey |
| Cooling type | Active |
| Fan diameter | 40 |
| Number of fans | 1 |
| LED indicators | Status |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 |
| Storage temperature (T-T) | -20 - 80 |
| Certificates | |
| Compliance certificates | CE |
| Certification | TUV, FCC, UL/cUL, CCC, CB 62368-1 & CB 60950-1 |
| Weight & dimensions | |
| Width | 220 |
| Depth | 81.5 |
| Height | 40.5 |
| Technical details | |
| Sustainability certificates | ENERGY STAR,ErP |
| Logistics data | |
| Harmonized System (HS) code | 85044030 |
| Other features | |
| Rise time | 20 |
