D-Link Wireless AC2600 Wave2 Nuclias Access Point
D-Link Wireless AC2600 Wave2 Nuclias Access Point, 2.4 GHz, 5 GHz, 2600 Mbit/s, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, 10,100,1000 Mbit/s
Availability: Arriving Soon
Cloud Networking, RefreshedThe DBA-2820P Access Point (AP) is part of the Nuclias Cloud solution – D-Link’s complete Cloud-Managed Networking solution for Small-to-Medium Businesses (SMBs), designed to make the ownership and administration of IT infrastructure as simple and hassle-free as possible. Built for Heavy WorkloadsThe DBA-2820P is a workhorse solution built to handle bandwidth-intensive applications involving numerous clients. It delivers high-speed wireless AC (Wave 2) connection reliably, with maximum wireless signal rates of up to 2.6Gbps, and 4 x 4 MU-MIMO (four spatial streams). Performance is further optimized via the Nuclias Cloud platform which adjusts the DBA-2820P’s channel selection, transmission power, and maximum number of client connections.Advanced Management & SecurityThe Nuclias Cloud interface lets admins easily manage Layer-2 features, such as VLANs, Spanning Tree Protocol (STP), and 802.3ad Link Aggregation (static). With SSID isolation, MAC address filtering, and end-to-end encryption, this is a versatile solution for those seeking easy configuration, without added complexities.Full PoE SupportThe DBA-2820P Access Point supports Power over Ethernet (IEEE 802.3at standard) for its Gigabit LAN port. Power over Ethernet greatly simplifies the installation of compatible devices such as VoIP phones and IP cameras in remote locations that lack easy access to a power outlet.
| Features | |
|---|---|
| 2.4 GHz | Y |
| 5 GHz | Y |
| Maximum data transfer rate | 2600 |
| Maximum data transfer rate (2.4 GHz) | 800 |
| Maximum data transfer rate (5 GHz) | 1733 |
| Ethernet LAN data rates | 10,100,1000 |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11h,IEEE 802.3ab,IEEE 802.3at,IEEE 802.3az,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| MIMO | Y |
| MIMO type | Multi User MIMO |
| Flow control support | Y |
| Transmitting power | 26 |
| Security | |
| Security algorithms | WPA-Enterprise,WPA-PSK,WPA2-Enterprise,WPA2-PSK |
| MAC address filtering | Y |
| Number of SSID supported | 16 |
| Protocols | |
| DHCP server | Y |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Y |
| Power | |
| Power over Ethernet (PoE) | Y |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Output voltage | 12 |
| Power consumption (max) | 21.65 |
| Power supply | 19.2 |
| Design | |
| Placement | Ceiling,Table,Wall |
| Product colour | White |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| On/off switch | Y |
| Reset button | Y |
| LED indicators | Y |
| Antenna | |
| Antenna type | Internal |
| Antenna direction type | Omni-directional |
| Antenna gain level (max) | 4 |
| Technical details | |
| Shipping (inner) case length | 419 |
| Shipping (inner) case width | 312 |
| Shipping (inner) case height | 328 |
| Shipping (inner) case net weight | 6925 |
| Products per shipping (inner) case | 5 |
| Pallet gross weight (air) | 206436 |
| Master (outer) cases per pallet (air) | 24 |
| Products per pallet (air) | 120 |
| Pallet gross length | 1100 |
| Pallet gross width | 1200 |
| Pallet height (air) | 1447 |
| Pallet gross weight (sea) | 253670 |
| Master (outer) cases per pallet (sea) | 30 |
| Products per pallet (sea) | 150 |
| Pallet height (sea) | 1775 |
| Shipping (inner) case gross weight | 7789 |
| Certificates | |
| Certification | CE B, FCC B, UL, IC B |
| Weight & dimensions | |
| Width | 224.5 |
| Depth | 223.85 |
| Height | 50 |
| Weight | 810 |
| Packaging data | |
| Package width | 294 |
| Package depth | 291 |
| Package height | 94 |
| Package weight | 1385 |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90 |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 65 |
| Storage relative humidity (H-H) | 5 - 95 |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
