D-Link Hi-speed USB 2.0 10/100 Ethernet Adapter
D-Link Hi-speed USB 2.0 10/100 Ethernet Adapter, Wired, USB, Ethernet, 100 Mbit/s, Black
Availability:: Arriving soon
The D-Link DUB-E100 is a Hi-Speed USB 2.0 10/100Mbps Fast Ethernet Adapter specifically designed to plug into an available Universal Serial Bus (USB) port on a desktop or laptop PC running Microsoft Windows XP, Me, 2000 or 98SE. Based on USB 2.0, the DUB-E100 extends the transfer speed of earlier USB Fast Ethernet adapters to true 10/100Mbps connectivity.As a USB device, the D-Link DUB-E100 eliminates the need to use an ISA, PCI, or PC Card slot to add LAN connectivity to a PC desktop or laptop computer. Installation and use are further simplified by living up to USB's out-of-the-box installation approach to connecting computer peripherals. You will not need to open the case of your computer, nor will you be required to set IRQ's. The D-Link DUB-E100 represents the simplest way to connect your computer to an Ethernet based network.The D-Link DUB-E100 provides a standard RJ-45 connector for a quick and simple method of connecting to an Ethernet 10Mbps or Fast Ethernet 100Mbps based LAN via a network hub or switch. The built-in USB 2.0 cable connects directly to your computer or laptop.Power for the DUB-E100 is provided directly by the USB bus, eliminating the need for an external power adapter. It also supports USB's energy saving suspend and resume functions to minimize power consumption, which is especially useful for laptop/notebook users.
| Ports & interfaces | |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
| Network | |
| Maximum data transfer rate | 100 |
| Networking standards | IEEE 802.3,IEEE 802.3u |
| Cabling technology | 10/100BaseT(X) |
| Full duplex | Y |
| Design | |
| Component for | PC |
| Product colour | Black |
| Internal | N |
| LED indicators | Link,Power |
| Certification | FCC Class B, CE Class B |
| Power | |
| Input current | 0.5 |
| Power consumption (typical) | 2.5 |
| Power consumption | 150 |
| System requirements | |
| Windows operating systems supported | Y |
| Mac operating systems supported | Y |
| Linux operating systems supported | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -10 - 70 |
| Operating relative humidity (H-H) | 5 - 95 |
| Storage relative humidity (H-H) | 0 - 95 |
| Weight & dimensions | |
| Width | 21.3 |
| Depth | 73 |
| Height | 20 |
| Weight | 22 |
| Packaging data | |
| Package width | 138 |
| Package depth | 138 |
| Package height | 30 |
| Package weight | 116 |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Shipping (inner) case net weight | 1880 |
| Shipping (inner) case length | 360 |
| Shipping (inner) case height | 345 |
| Shipping (inner) case width | 320 |
| Products per shipping (inner) case | 40 |
| Pallet gross weight (air) | 378000 |
| Master (outer) cases per pallet (air) | 45 |
| Products per pallet (air) | 1800 |
| Pallet height (air) | 1860 |
| Pallet gross weight (sea) | 378000 |
| Master (outer) cases per pallet (sea) | 45 |
| Products per pallet (sea) | 1800 |
| Pallet height (sea) | 1860 |
| Shipping (inner) case gross weight | 8400 |
| Pallet gross width | 1100 |
| Pallet gross length | 1200 |
| Other features | |
| Compliance industry standards | OHCI, EHCI |
| Supported data transfer rates | 10/100 |
| Ports quantity | 1 |
