APC Smart-UPS SMT2200IC - 8x C13, 1x C19, USB, SmartConnect, 2200VA
(0 review)Add your review
€1519,54

APC Smart-UPS SMT2200IC - 8x C13, 1x C19, USB, SmartConnect, 2200VA, Line-Interactive, 2.2 kVA, 1980 W, Sine, 151 V, 302 V

Availability: Arriving Soon
EAN:0731304337317Categories:Servers & StorageTags:

Stay always online and prevent data lossAs soon as the power fails, an APC Smart-UPS immediately supplies emergency power to all connected equipment. Because an APC UPS does this automatically, you prevent unwanted failure of, for example, a PC, server or switch. With the free APC PowerChute software, you can even have critical IT hardware shut down automatically and in a controlled manner when the battery of the UPS is almost empty. This prevents data loss, downtime and physical damage to hardware.SafetyIn addition, a Smart-UPS protects connected devices against peak voltage caused by lightning, among other things. This APC emergency power supply is ideally suited for (small) business use.Battery lifeYou can easily read the expected battery life in the runtime graph, which you can find between the product images. This makes it easy to see how long the UPS will supply emergency power at a certain load.SmartConnectOut-of-box remote UPS monitoring, free during a 6-month trial period. Using the SmartConnect Ethernet port, you can easily connect the Smart-UPS to your network and monitor it remotely via the secure APC SmartConnect cloud-based web portal*. In addition, the UPS can always be monitored via this port via EcoStruxure IT Expert (SFTWES1-DIGI).* Extend access to SmartConnect via the following licenses:1 year Standard Plan: ERWPMON1-1Y-DIGI3 years Standard Plan: ERWPMON1-3Y-DIGI1 year Advanced Plan: ERWPLUS1-1Y-DIGI3 years Advanced Plan: ERWPLUS1-3Y-DIGIPowerChuteBy connecting the UPS to a maximum of one server via a USB cable, it can automatically provide it with a shutdown signal during a prolonged power failure and thus still prevent a hard shutdown. This exact moment can be set via the free APC PowerChute Serial Edition software.Network Management CardIf you connect the UPS directly to your network via the optional APC Network Management Card (AP9640/AP9641), it can be easily managed remotely via SNMP or our remote management software Ecostruxure IT Expert (SFTWES1-DIGI). You can also automatically send a shutdown signal via the network to multiple physical and/or virtual servers. By means of the APC PowerChute Network Shutdown Software belonging to the network card, it is even possible to differentiate between the shutdown moment and the order in which this happens.Ease of useBy means of physical buttons and an LCD screen, it is possible to set and read out the basic functionalities.Extend the lifespanThe internal battery cartridge (RBC55) can be easily, safely and independently replaced by the user. This without having to switch off the APC SMT2200IC or connected equipment. This way you can easily and cheaply extend the life of the APC Smart-UPS and your equipment always stays online.Warranty extensionThe factory warranty of the SMT2200IC is 3 years, with the exception of the battery cartridge, which has a factory warranty of 2 years. Both are extended by 3 years to 6 and 5 years respectively with the APC service pack (WBEXTWAR3YR-SP-03).Switched Outlet Groups: Remote reboot and phased start-upThanks to the Switched Outlet Groups it is possible to configure a phased/delayed power-on per UPS outlet group. This reduces the peak load on the UPS and brings it closer to the constant load, which can limit oversizing of the UPS.It is also possible to reset a group of multiple UPS outlets and the equipment connected to them. If SmartConnect Advanced (ERWPLUS1-1Y-DIGI), a UPS with SmartConnect port + Ecostruxure IT Expert (SFTWES1-DIGI) or a network card (ap9640) in combination with Ecostruxure IT Expert (SFTWES1-DIGI) are used, this can even be done remotely.

Features
UPS topologyLine-Interactive
Output power capacity2.2
Output power1980
WaveformSine
Input operation voltage (min)151
Input operation voltage (max)302
Input frequency50/60
Output operation voltage (min)220
Output operation voltage (max)240
Surge energy rating365
Response time6
Emergency Power Off (EPO)Y
Output voltage Total Harmonic Distortion (THD)5
Noise level45
Power protection featuresOver voltage,Overload
Audible alarm(s)Y
Audible alarm modesAlarm when on battery,Low battery alarm,Battery replacement
Auto-restartY
Ports & interfaces
AC outlet typesIEC 60320
AC outlets quantity9
USB portY
USB 2.0 ports quantity1
USB port typeUSB Type-A
Serial interfaceY
Serial ports quantity1
Ethernet LAN (RJ-45) ports1
SmartSlotY
Battery
Battery technologySealed Lead Acid (VRLA)
Typical backup time at full load8.7
Typical backup time at half load25
Battery life (max)5
Battery recharge time3
Design
Product colourBlack
Display typeLCD
LED indicatorsY
Operational conditions
Operating temperature (T-T)0 - 40
Storage temperature (T-T)-15 - 45
Operating relative humidity (H-H)0 - 95
Storage relative humidity (H-H)0 - 95
Operating altitude0 - 3000
Non-operating altitude0 - 15000
Certificates
Compliance certificatesRoHS
CertificationCE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE
Packaging content
Cables includedRS-232,USB cable
Sustainability
Sustainability certificatesGreen Premium
Weight & dimensions
Width197
Depth544
Height435
Weight48800
Packaging data
Software CDY
Package width381
Package depth762
Package height699
Package weight61900
Logistics data
Products per pallet9
Harmonized System (HS) code85078000
Total carbon footprint (kg of CO2e)3715.93
