Vertiv ACS8048-EU-DAC-400 console server RJ-45
Vertiv ACS8048-EU-DAC-400, LOCAL,LDAP,RADIUS,TACACS+ and OneTimePasswords(OTP), 3DES, 128-bit AES, 192-bit AES, 256-bit AES, AES, FIPS 140-2, HTTPS, IPSec, SHA-256, SNMP, SNMPv3,..., RJ-45, C13 coupler, Embedded LINUX, 438.2 x 241.3 x 44.5 mm
Availability: Arriving Soon
The Vertiv Avocent ACS8000 Cellular advanced serial console server series delivers secure in-band and out-of-band visibility and control to downstream equipment in enterprise data centers, as well as cloud and colocation facilities. Now with cellular capabilities, the Vertiv Avocent ACS8000 Cellular provides flexibility to access devices when wired networks are down (failover) or unavailable at the device location. This serial console system serves as a secure management gateway and single point of entry keeping you connected to critical IT equipment even in the event of partial or total data center outages. With environmental monitoring, IoT integration, and remote networking abilities, the Vertiv Avocent ACS8000 Cellular is ideal for edge locations, enterprise data centers, and hyperscale or colocation facilities.
| Technical details | |
|---|---|
| Rack mounting | Y |
| Zero Touch Provisioning (ZTP) | Y |
| Web-based management | Y |
| 4G LTE | Y |
| Management features | |
| Management protocols | LOCAL,LDAP,RADIUS,TACACS+ and OneTimePasswords(OTP) |
| Security | |
| Security algorithms | 3DES,128-bit AES,192-bit AES,256-bit AES,AES,FIPS 140-2,HTTPS,IPSec,SHA-256,SNMP,SNMPv3,SSH,SSH-2 |
| IP address filtering | Y |
| One-time password (OTP) | Y |
| Ports & interfaces | |
| Console port | RJ-45 |
| Serial ports quantity | 48 |
| USB 2.0 ports quantity | 8 |
| Ethernet LAN (RJ-45) ports | 2 |
| SFP module slots quantity | 2 |
| AC outlet types | C13 coupler |
| Software | |
| Operating system installed | Embedded Linux |
| Weight & dimensions | |
| Dimensions (WxDxH) | 438.2 x 241.3 x 44.5 |
| Weight | 3400 |
| Power | |
| Power source type | AC |
| AC input voltage | 109 - 240 |
| AC input frequency | 50 - 60 |
| Power consumption (typical) | 7 |
| Power consumption (max) | 28 |
| Number of power supply units | 2 |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 60 |
| Storage temperature (T-T) | -20 - 70 |
| Operating relative humidity (H-H) | 50 - 60 |
| Storage relative humidity (H-H) | 20 - 80 |
| Memory | |
| Flash memory | 16000 |
| RAM capacity | 1024 |
| RAM type | DDR3L |
| eMMC capacity | 16 |
| Processor | |
| Processor family | ARM Cortex-A9 |
| Processor architecture | ARM Cortex-A9 |
| Processor cores | 2 |
| Processor frequency | 667 |
| Network | |
| Copper ethernet cabling technology | 10BASE-T,100BASE-T,1000BASE-T |
| Cable types supported | Cat5,Cat5e,Cat6,Cat6+,Cat6a,Cat6e,Cat7,Fiber |
