Lindy 47163 networking cable Red 1.5 m Cat6a S/FTP (S-STP)
(0 review)Add your review
€2,89

Lindy 47163, 1.5 m, Cat6a, S/FTP (S-STP), RJ-45, RJ-45, Red

Availability: Arriving Soon

Cat.6A S/FTP network cable with support for bandwidth up to 500MHz and features a snagless design with gold plated contacts for ethernet standards up to 10 GBase-T.Cat.6A cable, shielded with braid as overall shield and foil shield for the individual wire pairs (S/FTP). Cat.6A cables meet the requirements of 10 Gigabit Ethernet (10GBaseT) with an operating frequency of up to 500MHz. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.The halogen-free sheath material of the LSZH cable makes the product suitable for use in public spaces with its low smoke emission and elimination of toxic halogen emissions.Available lengths: 0.3m, 0.5m, 1m, 1.5m, 2m, 3m, 5m, 7.5m, 10m, 15m, 20m, 30m.Available colours: Black, Blue, Grey, Red, White

Features
Product colourRed
Cable length1.5 m
Cable standardCat6a
Cable shieldingS/FTP (S-STP)
Connector 1RJ-45
Connector 2RJ-45
Connector 1 genderMale connector
Connector 2 genderMale connector
Connector contacts platingNickel/Gold
Connector shieldingY
Connector shield materialAluminium
Jacket materialLow smoke zero halogen (LSZH)
Conductor materialCopper
Cable classE
Cabling technology10/100/1000Base-T(X)
AWG wire size27
Data transfer rate1000 Mbit/s
Frequency500 MHz
Bend radius (min)72 mm
Plug and PlayY
Operational conditions
Operating temperature (T-T)-10 - 60 °C
Storage temperature (T-T)-20 - 75 °C
Certificates
CertificationRoHS, REACH, UL
Weight & dimensions
Outer diameter6 mm
Connector 1 dimensions (WxDxH)11.6 x 21.5 x 8.3 mm
Connector 2 dimensions (WxDxH)11.6 x 21.5 x 8.3 mm
Packaging content
Quantity per pack1 pc(s)
Packaging data
Package typePolybag
Logistics data
Harmonized System (HS) code84733080
