Shuttle XPС slim PC XH510G2 Black Intel H510 LGA 1200 (Socket H5)
Shuttle XPС slim PC XH510G2, PC barebone, Intel H510, LGA 1200 (Socket H5), DDR4-SDRAM, M.2, PCI Express, Serial ATA III, 180 W
Availability:: Arriving soon
The Shuttle XPC slim Barebone XH510G2 is a 4.75-litre PC with two slots for PCI-Express expansion cards. Together with an LGA 1200 Intel Core desktop processor of the Intel Core Gen 10/11 range, this platform is perfectly suited for many professional applica-tions where performance, flexibility and a compact form factor matter. This includes video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible.
| Processor | |
|---|---|
| Built-in processor | N |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 2666,2933,3200 MHz |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Dual-channel |
| Non-ECC | Y |
| Storage | |
| Supported storage drive types | SSD |
| Storage drive sizes supported | 2.5,M.2 " |
| Storage drive interface | M.2,PCI Express,Serial ATA III |
| Card reader integrated | N |
| Graphics | |
| On-board graphics card | Y |
| Audio | |
| Built-in speaker(s) | N |
| Network | |
| Ethernet LAN | Y |
| Wi-Fi | N |
| LAN controller | Intel I219-LM |
| Ports & interfaces | |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0a |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Microphone in | Y |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Y |
| Expansion slots | |
| PCI Express slots version | 3.0,4.0 |
| PCI Express x1 slots | 1 |
| PCI Express x16 slots | 1 |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| On/off switch | Y |
| LED indicators | HDD,Power |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| VESA mounting | Y |
| Panel mounting interface | 100 x 75 mm |
| Product type | PC barebone |
| Performance | |
| Motherboard chipset | Intel H510 |
| Processor socket | LGA 1200 (Socket H5) |
| Number of processors supported | 1 |
| BIOS type | UEFI AMI |
| Trusted Platform Module (TPM) | Y |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio output channels | 7.1 channels |
| Logistics data | |
| Harmonized System (HS) code | 84713000 |
| Software | |
| Windows operating systems supported | Windows 10,Windows 11 |
| Linux operating systems supported | Y |
| Operating system installed | N |
| Power | |
| Power supply type | External AC adapter |
| Power supply | 180 W |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 19.5 V |
| AC adapter output current | 9.23 A |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Weight & dimensions | |
| Width | 250 mm |
| Depth | 200 mm |
| Height | 95 mm |
| Weight | 2980 g |
| Package weight | 3490 g |
| Packaging content | |
| Power cord included | Y |
| AC adapter included | Y |
| Quick start guide | Y |
| Drivers included | Y |
| Other features | |
| Country of origin | China |
