ATEN CE920R-ATA-G KVM extender Receiver
ATEN CE920R-ATA-G, Receiver, Wired, 100 m, 4096 x 2160 pixels, 30 Hz, 4096 x 2160 3840 x 2160
Availability: Arriving Soon
The ATEN CE920 USB DisplayPort HDBaseT™ 2.0 KVM Extender integrates the latest HDBaseT™ 2.0 technologies to deliver 4K video, stereo audio, USB, Ethernet, and RS-232 signals up to 100 meters using a single Cat6 / 2L-2910 Cat 6 cable. The HDBaseT™ 2.0 guarantees the most reliable transmission on the market as well as enables the long-reach capability that extends full HD 1080P signals up to 150 meters. With an easy cable installation supporting various signals, the CE920 is ideal for applications where convenient remote access is required – such as transportation control centers, medical facilities, industrial warehouses, and extended workstations.
| Features | |
|---|---|
| Type | Receiver |
| Connectivity technology | Wired |
| Maximum transfer distance | 100 |
| Maximum digital resolution | 4096 x 2160 |
| Maximum refresh rate | 30 |
| Supported resolutions | 4096 x 2160 3840 x 2160 |
| Product colour | Black |
| Material | Metal |
| Plug and Play | Y |
| LED indicators | Y |
| Ports & interfaces | |
| USB port type | USB Type-A |
| RS-232 ports | 1 |
| PC Audio in | Y |
| PC Audio out | Y |
| Power | |
| AC adapter output voltage | 5 |
| Weight & dimensions | |
| Receiver width | 121.9 |
| Receiver depth | 182 |
| Receiver height | 28.7 |
| Receiver weight | 640 |
| Packaging content | |
| AC adapter included | Y |
| Manual | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 60 |
| Operating relative humidity (H-H) | 0 - 80 |
| Storage relative humidity (H-H) | 0 - 80 |
| Technical details | |
| Dimensions (WxDxH) | 121.9 x 182 x 28.7 |
| Maximum resolution | 4096 x 2160 |
| Weight | 640 |
