Vertiv Geist MG05M4B0-30PN63-2PS56B2A10-S-A power distribution unit (PDU) 30 AC outlet(s) 0U Black
€1191,64
Vertiv Geist MG05M4B0-30PN63-2PS56B2A10-S-A, Monitored, 0U, Three-phase, Vertical, Black, LCD
Availability: Arriving Soon
Upgradeable Unit Level EC Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering a comprehensive view of input level power usage via remote network access. Includes environmental monitoring capabilities to obtain real-time environmental metrics. Upgrade the hot-swappable monitoring device on select units to leverage new technologies and accommodate changing business needs.
| Design | |
|---|---|
| PDU types | Monitored |
| Type | Three-phase |
| Rack capacity | 0U |
| Mounting | Vertical |
| Product colour | Black |
| Display | LCD |
| On/off switch | N |
| Ports & interfaces | |
| AC outlets quantity | 30 |
| Power plug | IEC 60309 |
| AC outlet types | C13 coupler,C19 coupler |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB ports quantity | 1 |
| Features | |
| Reset button | Y |
| Cable length | 3.05 |
| Management features | |
| Monitoring | Current,Power,Voltage |
| Supported network protocols | DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+, Modbus TCP |
| Power | |
| Nominal input voltage | 200-240/346-415 |
| AC input frequency | 50/60 |
| Maximum current | 16 |
| Nominal output voltage | 16 |
| Load capacity | 230 |
| Certificates | |
| Certification | CE Marked UKCA Marked Complies with IEC 62368-1 (DOC Available) Complies with EN 55032 and EN 55035 RoHS Compliant Cم Mark RCM Mark (EMC Only) China RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 45 |
| Weight & dimensions | |
| Width | 51 |
| Depth | 51 |
| Height | 1683 |
| Packaging data | |
| Package weight | 6800 |
