ASUS TUF GAMING 1200W Gold power supply unit 20+4 pin ATX ATX Black
(0 review)Add your review
€231,46

ASUS TUF GAMING 1200W Gold, 1200 W, 100 - 240 V, 130 W, 1188 W, 130 W, 9.6 W

Availability: Arriving Soon
EAN:4711081786252Categories:PowerTags:

The TUF Gaming 1200W Gold is an efficient, resilient and dependable PSU that’s engineered for the long haul.Built For The Long HaulThe ASUS TUF Gaming 1200W Gold packs military-grade strength, a flagship fan design, and PCB protection for efficient, durable power delivery. The result is a PSU that will reliably fuel your rig for years to come.​DurabilityTUF ComponentsTop marksWith military-grade components, including capacitors rated for 105°C operation and up to 170,000 hours’ lifespan, the ASUS TUF Gaming 1200W Gold empowers you to build in confidence.​Dual Ball Fan Bearings2x longer lifespanExemplary cooling is provided by a 135mm fan spinning on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design.Protective PCB CoatingAll wrapped upA protective conformal coating envelops the PCB to protect against short-circuits caused by moisture, dust, and debris.ENGINEERING80 Plus Gold CertificationHeart of goldThe TUF Gaming 1200W Gold features efficient, low-ESR Japanese capacitors to ensure efficient operation — affording it 80 PLUS® Gold status. This means it delivers up to 92% efficiency, resulting in less heat, reduced fan noise, and increased reliability.​ATX 3.1 CompatibleStep into the futureThe latest power specification updates have landed. ATX 3.1 ushers in tighter voltage and current regulation guidelines for next-gen hardware - and TUF Gaming 1200W Gold steps ahead of the curve by being fully compliant. A 16-pin PCIe cable ripe for piping up to 600W of power to PCIe Gen 5.0 graphics cards is bundled with the PSU, bringing large-scale capabilities.Axial-tech Fan DesignBetter, faster, strongerAxial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure. For TUF Gaming series PSUs, we've scaled that design to 135mm so it keeps things cool at low RPMs while producing less noise.EXPERIENCE10-year WarrantyA decade of power​We're so confident about the reliability of the TUF Gaming 1200W Gold that we back it with a 10-year worldwide warranty.​Fully Modular Etched CablesSupple plyThe included fully-modular cable set is etched to provide a similar aesthetic to sleeved cables but a touch more flexibility for tight spaces.

Power
Total power1200 W
AC input voltage100 - 240 V
Combined power (+3.3V)130 W
Combined power (+12V)1188 W
Combined power (+5V)130 W
Combined power (-12V)9.6 W
Combined power (+5Vsb)15 W
Max output current (+3.3V)25 A
Max output current (+12V)99 A
Max output current (+5V)25 A
Max output current (-12V)0.8 A
Max output current (+5Vsb)3 A
Efficiency92 %
Power protection featuresOver power,Over voltage,Overcharge,Overheating,Short circuit,Under power,Under voltage
Ports & interfaces
Motherboard power connector20+4 pin ATX
Motherboard power cable length610 mm
Number of SATA power connectors5
SATA power cable length120,400 mm
Peripheral (Molex) power connectors (4-pin)4
Peripheral (Molex) power cable length150,400 mm
PCI Express power connectors (8-pin)3
PCI Express power connectors (16-pin)2
PCI Express power cable length675 mm
CPU power connector (4+4 pin)Y
CPU power cable length650 mm
ATX power connector (20+4 pin)Y
Cabling typeFully-Modular
Performance
80 PLUS certification80 PLUS Gold
PurposePC
Power supply unit (PSU) form factorATX
ATX version3.1
Design
Product colourBlack
Cooling typeActive
Fan diameter135 mm
Number of fans1 fan(s)
On/off switchY
Packaging content
Cables includedAC,CPU,PCIe,Peripheral (Molex),SATA
Cable tie(s) includedY
Certificates
Compliance certificatesRoHS
Weight & dimensions
Width150 mm
Depth150 mm
Height86 mm
Weight2660 g
Packaging data
Package width310 mm
Package depth200 mm
Package height108 mm
Package weight3347 g
Package typeBox
Technical details
Sustainability complianceY
Logistics data
Warranty period10 year(s)
