GIGABYTE GAMING Radeon RX 7700 XT OC 12G AMD 12 GB GDDR6
GIGABYTE GAMING Radeon RX 7700 XT OC 12G, Radeon RX 7700 XT, 12 GB, GDDR6, 192 bit, 7680 x 4320 pixels, PCI Express 4.0
Availability:: Arriving soon
WINDFORCECOOLING SYSTEMThe WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 7 composite copper heat pipes, a large copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.ALTERNATE SPINNINGReduce the turbulence of adjacent fans and increase airflow pressure.3D ACTIVE FANThe 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.LARGE COPPER PLATE & HEAT-PIPEThe large copper plate directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.SCREEN COOLINGExtended heatsink allows air to pass through, providing better heat dissipation.RGB FUSIONWith 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.ULTRA DURABLEUltra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.FRIENDLY PCB DESIGNFully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.Power Through The GameGIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.GIGABYTE CONTROL CENTERGIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.AMD Radeon™ Anti-LagMinimizes input lag so you can game like a champion.AMD Radeon™ Image SharpeningImproves in-game visuals with virtually no impact to performance.AMD Noise SuppressionReduces background audio noise from your surrounding environment for clearer communication.AMD Radeon™ BoostDelivers extra performance and responsiveness when you need it most.AMD Radeon™ Super ResolutionIn-driver upscaler powered by FSR 1.0, elevates performance across thousands of games.In-driver upscaler powered by FSR 1.0, elevates performance across thousands of games.AMD LinkConnect your phone, tablet, TV, or Windows-based PC and play your games from almost anywhere in the world.
| Processor | |
|---|---|
| CUDA | N |
| Graphics processor family | AMD |
| Graphics processor | Radeon RX 7700 XT |
| Processor boost clock speed | 2599 MHz |
| Processor boost clock speed (Gaming mode) | 2276 MHz |
| Maximum resolution | 7680 x 4320 pixels |
| Stream processors | 3456 |
| Maximum displays per videocard | 4 |
| Memory | |
| Discrete graphics card memory | 12 GB |
| Graphics card memory type | GDDR6 |
| Memory bus | 192 bit |
| Memory bandwidth (max) | 18 GB/s |
| Ports & interfaces | |
| Interface type | PCI Express 4.0 |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 2.1 |
| USB Type-C ports quantity | 1 |
| Performance | |
| TV tuner integrated | N |
| DirectX version | 12 Ultimate |
| OpenGL version | 4.6 |
| Dual Link DVI | N |
| AMD FreeSync | Y |
| Design | |
| Cooling type | Active |
| Cooling technology | Gigabyte WATERFORCE |
| Number of fans | 3 fan(s) |
| Form factor | Full-Height/Full-Length (FH/FL) |
| Bracket height | Full-Height (FH) |
| Illumination | Y |
| Illumination colour | Multi |
| Product colour | Black |
| Power | |
| Minimum system power supply | 700 W |
| Supplementary power connectors | 2x 8-pin |
| System requirements | |
| Windows operating systems supported | Windows 10 x64,Windows 11 x64 |
| Weight & dimensions | |
| Length | 302 mm |
| Depth | 56 mm |
| Height | 130 mm |
| Packaging data | |
| Package type | Box |
| Packaging content | |
| User guide | Y |
