ATEN HDMI HDBaseT-Lite/Class B Receiver with Scaler function (70m)
€456,37
ATEN HDMI HDBaseT-Lite/Class B Receiver with Scaler function (70m), 1920 x 1080 pixels, AV receiver, 60 m, Black, HDCP
Availability:: Arriving soon
EAN:4719264642944Categories:AV Equipment
The VE805R HDMI HDBaseT-Lite Receiver with Scaler can be combined with ATEN HDMI HDBaseT products to extend your HDMI display up to 60 m from your HDMI source device using a single Cat 5e/6a cable.1x VE805R HDMI HDBaseT-Lite Receiver with Scaler1x 0AD6-1F05-26EG Power Adapter1x 2XRT-0003G IR Transmitter1x 2XRT-0004G IR Receiver1x Terminal Block1x User Instructions
| Features | |
|---|---|
| Type | AV receiver |
| Maximum resolution | 1920 x 1080 |
| Cable types supported | Cat5e,Cat6,Cat6a |
| Maximum transfer distance | 60 |
| Supported video modes | 1080p |
| On/off switch | Y |
| Class | B |
| HDCP | Y |
| Material | Metal |
| Wall mountable | Y |
| Impedance | 100 |
| HDCP version | 1.4 |
| Product colour | Black |
| Ports & interfaces | |
| RJ-45 input ports | 1 |
| Number of HDMI outputs | 1 |
| HDMI version | 1.4 |
| RS-232 input ports | 1 |
| Remote (IR) input | 1 |
| DC-in jack | Y |
| Power | |
| Operating voltage | 5 |
| Power consumption (typical) | 9.5 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 |
| Storage temperature (T-T) | -20 - 60 |
| Operating relative humidity (H-H) | 0 - 80 |
| Weight & dimensions | |
| Width | 169.2 |
| Depth | 177.4 |
| Height | 42 |
| Weight | 1050 |
| Packaging data | |
| Package width | 98 |
| Package depth | 325 |
| Package height | 210 |
| Package weight | 1240 |
| Logistics data | |
| Master (outer) case width | 342 |
| Master (outer) case length | 512 |
| Master (outer) case height | 232 |
| Master (outer) case gross weight | 6850 |
| Master (outer) case net weight | 5250 |
| Products per master (outer) case | 5 |
