Zyxel GS2220-50-EU0101F network switch Managed L2 Gigabit Ethernet (10/100/1000) Black
Zyxel GS2220-50-EU0101F, Managed, L2, Gigabit Ethernet (10/100/1000), Rack mounting
Availability: Arriving Soon
Designed for converged networksGS2220 SeriesZyxel’s new generation of Layer 2 Managed Switch GS2220 Series are fully featured Layer 2 Gigabit access switches designed to meet converged data, video and voice networking needs. This latest series’ eye-catching new look comes in 10-, 28-, and 50-port models with a combination of PoE and non-PoE. On top of the fully manageable L2 features set comes with the state-ofart Zyxel NebulaFlex Pro technology for cloud manageability.Industry first tri-mode switch.The GS2220 Series is the first managed hybrid switch with Nebula Cloud management, Standalone management, and SNMP.Powerful L2 features.The GS2220 Series has a rich Layer 2 feature set that can shape the traffic for diverse VoIP, video conference and IPTV deployments. Advanced traffic control features of the GS2220 Series such as L2 multicast, IGMP snooping, MVR provide businesses greater agility and more effective traffic management for the converged applications of today. Manage it your way!The support of Zyxel NebulaFlex Pro allows you to easily switch standalone management and intuitive Nebula cloud management platform with 1-YEAR Pro Pack bundled anytime with just a few simple clicks. Experience whisper-silent operations.This Series includes both fan-less and built-in smart fan models. The smart fan is designed to automatically adjust speed based on device temperature. You can barely hear the sound while the switch is operating.Flexible port combination.The GS2220 Series includes copper ports and combo ports, 50 and 50HP models even come with additional dedicated SFP ports for uplinks. This flexible port combination can fit in every Layer 2 switching applications easily.Plug into the power of the Zyxel One Network.The Zyxel One Network (ZON) Utility is a unified installation tool to discover and configure Zyxel Switches, WLAN and Gateways in the standalone network. Users can easily maintain the network in a single platform. ZON Utility is a free of charge tool which has been downloaded by over 32,000 users to date.
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Configuring Location Settings (CLI) | Y |
| System event log | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 44 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 4 |
| Fiber ports quantity | 2 |
| Fiber optic connector | SFP |
| Network | |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-TX,1000BASE-T |
| Port mirroring | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Spanning tree protocol | Y |
| VLAN support | Y |
| Virtual LAN features | Port-based VLAN,Private VLAN,Protocol-based VLAN,Voice VLAN |
| Optical fiber | |
| Fiber ethernet cabling technology | 1000BASE-X |
| Data transmission | |
| Switching capacity | 100 |
| Forwarding rate | 74 |
| MAC address table | 16000 |
| Packet buffer memory | 1.5 |
| Security | |
| DHCP features | DHCP client,DHCP relay,DHCP snooping,DHCPv6 client,DHCPv6 relay |
| Access Control List (ACL) | Y |
| IGMP snooping | Y |
| Security algorithms | SNMP,SNMPv2,SNMPv3,SSH-2,SSL/TLS |
| MAC address filtering | Y |
| Authentication | Guest VLAN,MAC-based authentication |
| Authentication type | IEEE 802.1x,RADIUS |
| Multicast features | |
| Multicast support | Y |
| Design | |
| Rack mounting | Y |
| Product colour | Black |
| Performance | |
| Internal memory | 256 |
| Flash memory | 32 |
| Noise level | 47.3 |
| Mean time between failures (MTBF) | 660245 |
| Power | |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Power consumption (max) | 36.9 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | N |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 |
| Storage temperature (T-T) | -40 - 70 |
| Operating relative humidity (H-H) | 10 - 95 |
| Storage relative humidity (H-H) | 10 - 95 |
| Heat dissipation | 125.829 |
| Weight & dimensions | |
| Width | 440 |
| Depth | 200 |
| Height | 44.5 |
| Weight | 2900 |
| Packaging content | |
| Cables included | AC |
| Packaging data | |
| Package width | 496 |
| Package depth | 289 |
| Package height | 90 |
| Package weight | 3970 |
| Certificates | |
| Certification | LVD, BSMI FCC 15 A, CE EMC A, BSMI ENC RoHS A |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
