APC E3SUPS10K3IB uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W
APC E3SUPS10K3IB, Double-conversion (Online), 10 kVA, 10000 W, 304 V, 477 V, 45/65 Hz
Availability: Arriving Soon
Easy UPS 3S 10 kVA 400 V 3:1 UPS for internal batteriesHigh-efficiency 3-phase UPS that features advanced product features, competitive specifications, and robust electrical design, making business continuity easy in the data center or electrical room. This is an exceptionally easy to install, operate, maintain, and service 10 kVA UPS, ideal for small and medium businesses. Includes dust filter and conformance-coated boards for harsh environments. This UPS is for internal batteries, but is supplied without batteries, so you can easily customize the battery runtime. For battery runtime details, see the runtime charts published under the Documents tab.Includes: Dust filter, Installation guideOptional SNMP CardWhen you purchase the SNMP card, you can monitor and manage UPS status remotely through the UPS Web interface or through EcoStruxure IT's cloud-based and on-premise software suites. Click here for more information about EcoStruxure IT.Replaceable dust filtersprotect the UPS in harsh environments.Parallel capabilityMultiple units can be placed in parallel to meet power capacity and redundancy requirementsWide Input Voltage WindowSaves your battery power for when you really need it - during power cuts!Easy Loop TestVerifies UPS performance before you connect your load, without the need for a load bank.Intuitive user interfaceThe intuitive graphical user interface allows for easy system configuration.Easy to install fastQuickly roll the compact and lightweight UPS into position.ECO ModeOperating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protectionFront-access servicingSimplifies installation and UPS maintenance while minimizing space requirements.Straightforward installationIncluding the input, output, and bypass breakers, as well as the Emergency Power Off (EPO) switch, simplifies installation planning and speeds up deployment.
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 10 |
| Output power | 10000 |
| Input operation voltage (min) | 304 |
| Input operation voltage (max) | 477 |
| Input frequency | 45/65 |
| Output operation voltage (min) | 220 |
| Output operation voltage (max) | 240 |
| Output frequency | 50/60 |
| Maximum current | 18 |
| Power factor | 0.99 |
| Crest factor | 3:1 |
| Output voltage Total Harmonic Distortion (THD) | 5.5 |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 240 |
| Design | |
| Form factor | Rackmount |
| Product colour | White |
| International Protection (IP) code | IP20 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -25 - 55 |
| Operating relative humidity (H-H) | 0 - 95 |
| Storage relative humidity (H-H) | 0 - 95 |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE |
| Packaging content | |
| Manual | Y |
| Weight & dimensions | |
| Width | 380 |
| Depth | 907 |
| Height | 1400 |
| Weight | 130000 |
| Packaging data | |
| Package width | 563 |
| Package depth | 1014 |
| Package height | 1640 |
| Package weight | 145000 |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
