ASUS ROG STRIX 750W GOLD (16-pin cable) power supply unit 24-pin ATX ATX Black
ASUS ROG STRIX 750W GOLD (16-pin cable), 750 W, 100 - 240 V, 100 W, 744 W, 100 W, 3.6 W
Availability: Arriving Soon
Frozen SilenceThe ROG Strix Series PSUs bring high-end cooling and premium components together for an ultra-quiet high-performance product aimed at core gamers. In terms of cooling, massive ROG heatsinks trickle down from the mighty ROG Thor series and Axial-tech fan design from our premium NVIDIA RTX™ graphics cards also make an appearance. Below the surface, low RDS (on) MOSFETs and premium Japanese capacitors take on power delivery with ease. The result is an incredibly quiet and efficient power supply with the reserves to handle the most intense gaming scenarios.ROG HeatsinksLet it sink inThe integrated ROG heatsinks have 2x more volume than traditional designs, resulting in significantly lower temperatures inside Strix PSUs. This extends the lifespan of components and allows 0dB operation for a longer duration than standard designs. The heatsinks are so effective that fan noise stays whisper quiet, even under full load.80 Plus Gold CertificationHeart of goldTop-end Japanese capacitors ensure efficient operation and have helped the Strix earn an 80 PLUS Gold certification. The increased efficiency also results in less heat, reducing noise and increasing reliability.Cosmetic CustomizationAestheticGetting everything looking right can be a challenging aspect of any setup. The ROG Strix Series PSUs aim to make your life a little easier with a convenient magnetic logo and stickers that help you reskin the visible side to your liking.
| Power | |
|---|---|
| Total power | 750 |
| AC input voltage | 100 - 240 |
| Combined power (+3.3V) | 100 |
| Combined power (+12V) | 744 |
| Combined power (+5V) | 100 |
| Combined power (-12V) | 3.6 |
| Combined power (+5Vsb) | 15 |
| Max output current (+3.3V) | 20 |
| Max output current (+12V) | 62 |
| Max output current (+5V) | 20 |
| Max output current (-12V) | 0.3 |
| Max output current (+5Vsb) | 3 |
| Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage |
| Ports & interfaces | |
| Motherboard power connector | 24-pin ATX |
| Motherboard power cable length | 610 |
| Number of SATA power connectors | 8 |
| SATA power cable length | 120,150,450 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| Peripheral (Molex) power cable length | 120,450 |
| PCI Express power connectors (6+2 pin) | 3 |
| PCI Express power connectors (16-pin) | 1 |
| PCI Express power cable length | 675 |
| CPU power connector (4+4 pin) | Y |
| CPU power cable length | 1000 |
| Cabling type | Fully-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| Bearing technology | DBB |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 135 |
| Number of fans | 1 |
| Fan location | Top |
| On/off switch | Y |
| Packaging content | |
| Cables included | CPU,PCIe,Peripheral (Molex),SATA |
| Certificates | |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 160 |
| Depth | 150 |
| Height | 86 |
| Weight | 1820 |
| Packaging data | |
| Package width | 310 |
| Package depth | 180 |
| Package height | 115 |
| Package weight | 3170 |
| Package type | Box |
