Ubiquiti UISP-R-EU | Router | MicroPoP, 8x RJ45 1000Mb/s, 1x SFP, 110W
Ubiquiti UISP-R-EU | Router | MicroPoP, 8x RJ45 1000Mb/s, 1x SFP, 110W
Availability: Arriving Soon
Ubiquiti UISP-R-EUThe Ubiquiti UISP Router (UISP-R) is a Gigabit PoE router designed with MicroPoP applications in mind, featuring 8 Gigabit Ethernet PoE ports and 1 SFP slot for an additional master link option. It is ideal for wireless ISP (WISP) deployments to deliver gigabit wireless speeds quickly and cost-effectively.Effectiveness and Efficiency for your NetworkThe UISP-R router is a cost-effective solution for WISP providers that want to deliver gigabit speeds to their customers. Equipped with a dual-core processor clocked at 880 MHz and 512 MB of DDR3 RAM, the UISP-R will perform well in a wide range of applications - not only carriers, but also smaller businesses, offering reliable performance and stable operation.Powerful PoEWith a powerful 110 Watt PoE power supply, the UISP router delivers significant power to every radio in your service network. There is a PoE power output on each Ethernet port, supporting passive PoE at 27 V DC. The maximum output power per port is 30 watts, and 110 watts for the entire device, with a maximum power consumption of only 10 watts for the UISP-R itself. A 27 V DC, 4.4 A power supply is included for stable power supply.Advanced Management with UISP ApplicationThe UISP router is managed using the UISP application, a centralized platform for monitoring and managing all UISP devices. The router supports basic management functions such as DHCP server, firewall configuration, changing PoE settings, and backup and restore. The UISP platform can be used through both a web browser and a mobile app, offering convenient and transparent network management in one place. In addition, the platform has functions related to subscriber accounts and payments, making it a comprehensive tool for any ISP.Note: The UISP router is managed by the UISP app version 1.4.0 or later.
Number of LAN ports8x [10/100/1000M (RJ45)]Number of LAN ports1x SFP (1,25G)3G/4G USB modem compatibilityNoAC adapter includedYesCabling technology10/100Base-T(X)CertificationCE, FCC, ICDC-in jackYesDepth95Ethernet interface typeGigabit EthernetEthernet LAN (RJ-45) ports8Ethernet WANYesFlash memory512Harmonized System (HS) code85176990Height29Installed SFP modules quantity1Internal memory512LED indicatorsActivity, LAN, Link, PoE, Power, Speed, WAN, WLANManagementBy web browserManagementCLI - Command Line InterfaceManagementDedicated applicationManualYesNumber of CPU cores2Operating relative humidity (H-H)5 - 95Operating temperature (T-T)-10 - 50Output current4.4Output voltage24 - 28Power consumption (typical)10Power over Ethernet (PoE)YesPower over Ethernet (PoE) ports quantity8Power source typeDC, PoEProcessor frequency880Processor modelMIPS 1004KcProduct colourWhiteQuick start guideYesRAM memory512MBSIM card slotNoType of casePlasticType of caseDesktopType of device power supplyPower supplyWeight600Width210.4
