MSI MPG B850 EDGE TI WIFI motherboard AMD B850 Socket AM5 ATX
(0 review)Add your review
€300,96

MSI MPG B850 EDGE TI WIFI, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, 256 GB, DDR5-SDRAM

Availability:: Arriving soon
EAN:4711377290616Categories:Hardware Components

MPG B850 EDGE TI WIFI is covered with a silver-white color scheme for white PC build lovers to show off different identity. It is also powerful because of its true Wi-Fi 7 solution, 5G LAN and the latest PCIe 5.0 compatibility, Supplemental PCIe Power, and this is the best white theme B850 ATX motherboard for AMD Ryzen™ 9000 series processors.MSI's premium MPG series is engineered for gamers who demand strong performance and sleek design. Each product showcases cutting-edge aesthetics and vibrant colors, reflecting MPG's commitment to exceptional design. With optimized configurations, MPG creates a visually striking and powerful gaming experience that leads the trends.MSI motherboards are designed with advanced hardware and technology, well-supporting the demanding computing usage of gaming and AI. Moreover, we also introduce AI to MSI Center and BIOS, making everything more effortless than before.EZ PCIe ReleaseAn easy-to-access physical button release mechanism that can help remove any PCIe card with a single tap, making it much easier to upgrade to a new GPU or other compatible device, streamlining the entire process and enhancing user experience.14+2+1 DUET RAIL POWER SYSTEMUnleash and sustain the maximum performance with a flagship VRM design built with a total of 14+2+1 Duet Rail Power System. Combining dual power connectors and 80A Smart Power Stage, MPG B850 EDGE TI WIFI is ready for the challenge of high-end processors.Extended HeatsinkExtended Heatsink enlarges the surface of heat dissipation and maintain the performance at heavy loads.M.2 Shield FrozrKeeps M.2 SSDs safe while preventing throttling, making them run faster.M.2 Shield FrozrKeeps M.2 SSDs safe while preventing throttling, making them run faster.7W/mK Thermal Pad & Additional Choke PadHigh-quality 7W/mK MOSFET thermal pads and additional choke thermal pads ensure stable performance when all cores are runnging at high speed.Enlarged Chipset HeatsinkThe enlarged heatsink is designed to reduce dust and noise and capable of maintaining high efficiency of heat dissipation.HIGH-BANDWIDTH AND LOW-LATENCY NETWORKMSI's premium network solution provides incredible data transfer speed for demanding users.

Processor
Processor manufacturerAMD
Processor socketSocket AM5
Compatible processor seriesAMD Ryzen 7000 Series,AMD Ryzen 8000 Series,AMD Ryzen 9000 Series
Supported processor socketsSocket AM5
Maximum internal memory supported by processor256
Memory
Supported memory typesDDR5-SDRAM
Number of memory slots4
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilitynon-ECC
Supported memory clock speeds4800,5600,8400
Supported memory clock speed (max)8400
Maximum internal memory256
Storage controllers
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2,Micro SATA III
Number of HDDs supported4
Number of storage drives supported8
RAID supportY
RAID levels0,1,10
Graphics
On-board graphics cardN
Internal I/O
USB 2.0 connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors4
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
Number of SATA III connectors4
Total number of SATA connectors4
CPU fan connectorY
Number of CPU fan connectors6
Number of water pump connectors1
RGB LED pin headerY
Number of RGB LED pin headers3
Rear panel I/O ports
USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity3
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
HDMI version2.1
Network
Ethernet LANY
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiY
Top Wi-Fi standardWi-Fi 7 (802.11be)
Wi-Fi standards802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax),Wi-Fi 6E (802.11ax),Wi-Fi 7 (802.11be)
BluetoothY
Bluetooth version5.4
Features
Motherboard chipsetAMD B850
Audio chipRealtek ALC4080
Audio output channels7.1
Product colourWhite
Component forPC
Motherboard form factorATX
Motherboard chipset familyAMD
Windows operating systems supportedWindows 11 x64
Expansion slots
PCI Express x16 (Gen 3.x) slots1
PCI Express x16 (Gen 4.x) slots1
PCI Express x16 (Gen 5.x) slots1
Number of M.2 (M) slots4
1st M.2 largest key size22110
1st M.2 highest PCI Express generation5.0
2nd M.2 largest key size2280
2nd M.2 highest PCI Express generation5.0
3rd M.2 largest key size2280
3rd M.2 highest PCI Express generation4.0
4th M.2 largest key size2280
4th M.2 highest PCI Express generation4.0
Weight & dimensions
Width304.8
Depth243.84
