GIGABYTE R282-Z97 Socket SP3 Rack (2U)
GIGABYTE R282-Z97, Socket SP3, AMD, AMD, DDR4-SDRAM, 256 GB, 2933,3200 MHz
Availability: Arriving Soon
Nothing Stacks Up To EPYC™AMD EPYC™ 7003 Processors with AMD 3D V-Cache™AMD EPYC 7003 Series Processors with AMD 3D V-Cache™ technology are raising the bar once more for breakthrough performance on targeted technical computing workloads like Electronic Design Automation, Computational Fluid Dynamics, and Finite Element Analysis software and solutions. Delivering breakthrough performance per core and performance per watt, the Zen 3 architecture maintains leadership in number of cores – up to 64, amount of L3 cache – 768MB, and 128 PCIe 4.0 lanes, while maintaining socket compatibility with existing 3rd Gen AMD EPYC platforms.
| Processor | |
|---|---|
| Built-in processor | N |
| Processor socket | Socket SP3 |
| Processor manufacturer | AMD |
| Processor family | AMD |
| Number of processors supported | 2 |
| Memory | |
| Number of DIMM slots | 32 |
| Supported memory types | DDR4-SDRAM |
| Maximum RDIMM memory | 256 |
| Supported RDIMM clock speeds | 2933,3200 |
| Storage | |
| Number of storage drives supported | 12 |
| Hot-swap HDD bays | Y |
| Number of 3.5" bays | 12 |
| Storage drive sizes supported | 2.5 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | Serial ATA,Serial Attached SCSI (SAS) |
| Graphics | |
| On-board graphics card model | Aspeed AST2500 |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10,100,1000 |
| LAN controller | Intel I350-AM2 |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 1 |
| COM ports quantity | 1 |
| Expansion slots | |
| PCI Express slots version | 4.0 |
| PCI slots | 7 |
| PCI Express x24 Riser Super slots | 1 |
| Number of M.2 (M) slots | 1 |
| Features | |
| Trusted Platform Module (TPM) | Y |
| Trusted Platform Module (TPM) version | 2.0 |
| Backplanes support | Y |
| Compatible operating systems | Windows Server 2016 ( X2APIC/256T not supported) Windows Server 2019 Red Hat Enterprise Linux 8.3 ( x64) or later SUSE Linux Enterprise Server 12 SP5 ( x64) or later SUSE Linux Enterprise Server 15 SP2 ( x64) or later Ubuntu 18.04.5 LTS (x64) or later Ubuntu 20.04 LTS (x64) or later VMware ESXi 6.7 Update3 P03 or later VMware ESXi 7.0 Update1 or later Citrix Hypervisor 8.2.0 or later |
| Logistics data | |
| Harmonized System (HS) code | 84714100 |
| Design | |
| Chassis type | Rack (2U) |
| LED indicators | HDD,LAN,Status |
| Power | |
| Power supply | 2000 |
| Number of main power supplies | 2 |
| Redundant power supply (RPS) support | Y |
| AC input voltage | 110 - 240 |
| DC output current (+5 V) | 81 |
| DC output current (+12 V) | 163 |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 35 |
| Storage temperature (T-T) | -40 - 60 |
| Operating relative humidity (H-H) | 8 - 80 |
| Storage relative humidity (H-H) | 20 - 95 |
| Weight & dimensions | |
| Width | 438 |
| Depth | 87 |
| Height | 730 |
| Packaging data | |
| Packaging content | 1 x R282-Z96 system 2 x CPU heatsinks 1 x Rail kit |
| Package width | 982 |
| Package depth | 588 |
| Package height | 268 |
