Shuttle XPC Nano PC NC40U, Intel Celeron 7305U, 1x HDMI, 1x DP,1xUSB-C/DP, 6x USB3.2, 1x 2.5" bay, 2x M.2, 1x LAN, RAID, 24/7 permanent operation, incl. VESA & Stand
Shuttle XPC Nano PC NC40U, Intel Celeron 7305U, 1x HDMI, 1x DP,1xUSB-C/DP, 6x USB3.2, 1x 2.5" bay, 2x M.2, 1x LAN, RAID, 24/7 permanent operation, incl. VESA & Stand, 0.84L sized PC, Mini PC barebone, Intel SoC, DDR4-SDRAM, PCI Express, Serial ATA III, 65 W
Availability:: Arriving soon
Many ports and high performance in nano formatThe NC40U series comes with powerful and efficient 12th generation Intel Core processors, codenamed "Alder Lake-U". Despite the nano format with only 850 ml volume, it offers enormous connection variety and expansion options. Thus, up to three UHD displays (4K/60Hz) and up to seven USB 3.2 devices can be connected, and two NVMe/SSD cards in M.2-2280 format as well as one 2.5" hard drive (up to 15 mm thickness) can be installed. The NC40U series is ideal for Digital Signage, POS, control, office or even multimedia.
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Celeron |
| Processor model | 7305 |
| Processor cores | 5 |
| Processor threads | 5 |
| Processor frequency | 1.1 |
| Performance cores | 1 |
| Efficient cores | 4 |
| Built-in processor | Y |
| Processor cache | 8 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 |
| Supported memory clock speeds | 3200 |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Dual-channel |
| Memory voltage | 1.2 |
| ECC | N |
| Non-ECC | Y |
| Storage | |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,M.2 |
| Storage drive interface | PCI Express,Serial ATA III |
| NVMe | Y |
| Number of storage drives supported | 3 |
| Card reader integrated | N |
| Graphics | |
| On-board graphics card | Y |
| Graphics card family | Intel |
| On-board graphics card model | Intel UHD Graphics |
| Maximum resolution | 7680 x 4320 |
| Audio | |
| Built-in speaker(s) | N |
| Network | |
| Ethernet LAN | Y |
| Wi-Fi | N |
| LAN controller | Intel I219 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0b |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4a |
| Microphone in | Y |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Y |
| Expansion slots | |
| PCI Express slots version | 3.0,4.0 |
| Number of M.2 (M) slots | 2 |
| Design | |
| Chassis type | 0.84L sized PC |
| Product colour | Black |
| Cooling type | Active |
| On/off switch | Y |
| LED indicators | HDD,Power |
| Housing material | Plastic |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| VESA mounting | Y |
| Panel mounting interface | 75 x 75,100 x 100 |
| Product type | Mini PC (<= 3L) barebone |
| Safety | CB IEC60950/62368, cTUVus (UL 62368) |
| Performance | |
| Motherboard chipset | Intel SoC |
| Number of processors supported | 1 |
| BIOS type | AMI |
| Trusted Platform Module (TPM) | Y |
| Trusted Platform Module (TPM) version | 2.0 |
| Technical details | |
| Compliance certificates | BSMI,CE,Federal Communications Commission (FCC),RoHS,UKCA |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Software | |
| Windows operating systems supported | Windows 10,Windows 11 |
| Linux operating systems supported | Y |
| Operating system installed | N |
| Sustainability | |
| Sustainability compliance | Y |
| Sustainability certificates | ENERGY STAR,ErP |
| Power | |
| Power supply type | External AC adapter |
| Power supply | 65 |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| AC adapter output voltage | 19 |
| AC adapter output current | 3.42 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | 10 - 90 |
| Weight & dimensions | |
| Width | 142 |
| Depth | 142 |
| Height | 42 |
| Weight | 400 |
| Package weight | 1200 |
| Packaging content | |
| Power cord included | Y |
| AC adapter included | Y |
| Quick start guide | Y |
| Drivers included | Y |
