iiyama TF3239AS-B1AG computer monitor 80 cm (31.5") 1920 x 1080 pixels Full HD LED Touchscreen Black
iiyama TF3239AS-B1AG, 80 cm (31.5"), 1920 x 1080 pixels, Full HD, LED, 8 ms, Black
Availability:: Arriving soon
Enjoy an all-in-one interactive display that combines the best in PCAP Touchscreen technology, offering the versatility and freedom of Android OS, easily customized to your needs by installing applications directly to it. Offering a powerful, yet flexible user experience, fostering creative communication with the benefits of a secure and controllable Touchscreen. The refined edge-to-edge glass design of the TF3239AS-B1AG lends itself for integration into a large variety of environments where polished design and functionality are needed, like Huddle spaces in the modern office space, Retail shops and Kiosks. The on-board iiSignage² CMS (Content Management System) gives you total control of your messaging and advertising, remotely and safely. The EShare App enables you to bring effortless ideation and efficient collaboration in your enterprise or school. You can start sharing wireless easier than ever before; while the FailOver feature ensures your content is always actively displayed through your choice of inputs For ease of integration, the TF3239AS-B1AG can be equipped with optional external mounting brackets ( OMK4-4 ).
| Display | |
|---|---|
| Display diagonal | 31.5 " |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Panel type | IPS |
| LED backlight | Y |
| Touchscreen | Y |
| Touchscreen technology | Projected capacitive system |
| Number of simultaneous touchpoints | 40 |
| Display brightness (typical) | 500 cd/m² |
| Display brightness | 500 cd/m² |
| Response time | 8 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Display surface | Matt |
| Anti-glare screen | Y |
| Screen shape | Flat screen |
| Contrast ratio (typical) | 1200:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.363 x 0.363 mm |
| Horizontal scan range | 28 - 160 kHz |
| Viewable size, horizontal | 698.4 mm |
| Viewable size, vertical | 392.8 mm |
| Display diagonal (metric) | 80 cm |
| Haze rate | 25 % |
| Surface hardness | 7H |
| Colour depth | 8 bit |
| Performance | |
| Operating hours (hours/days) | 24/7 |
| Operating system installed | Android |
| Operating system version | 11 |
| Multimedia | |
| Number of speakers | 2 |
| RMS rated power | 20 W |
| Built-in speaker(s) | Y |
| Design | |
| Product colour | Black |
| Front bezel colour | Black |
| Glass thickness | 3 mm |
| Ports & interfaces | |
| USB version | 2.0 |
| USB Touch port | Y |
| DVI port | N |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| HDCP | Y |
| HDCP version | 2.2 |
| RS-232C | Y |
| Network | |
| Ethernet LAN | Y |
| Ergonomics | |
| VESA mounting | Y |
| Panel mounting interface | 200 x 200 mm |
| On Screen Display (OSD) | Y |
| On Screen Display (OSD) languages | CZE,DAN,DEU,DUT,ENG,ESP,FIN,FRE,ITA,POL,RUS,SLV |
| Number of OSD languages | 13 |
| Power | |
| Energy efficiency class (SDR) | F |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 31 kWh |
| Power consumption (typical) | 50 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | Internal |
| Energy efficiency scale | A to G |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Weight & dimensions | |
| Width (with stand) | 746.2 mm |
| Depth (with stand) | 62.4 mm |
| Height (with stand) | 440.7 mm |
| Weight (with stand) | 13200 g |
| Bezel width (side) | 22 mm |
| Bezel width (top) | 22 mm |
| Bezel width (bottom) | 22 mm |
| Packaging data | |
| Package width | 840 mm |
| Package depth | 840 mm |
| Package height | 560 mm |
| Package weight | 16600 g |
| Packaging content | |
| Cables included | AC,DisplayPort,HDMI,USB |
| Remote control included | Y |
| Remote control batteries included | Y |
| Quick start guide | Y |
| Batteries included | Y |
| Other features | |
| International Protection (IP) code | IP65 |
| Positional accuracy | 2.5 mm |
| Placement supported | Indoor |
| USB connector type | USB Type-A,USB Type-B |
| Built-in processor | Y |
| Active display area (W x H) | 698.4 x 392.8 mm |
| Multi-touch | Y |
| USB ports quantity | 3 |
| Mean time between failures (MTBF) | 50000 h |
| Ethernet LAN (RJ-45) ports | 1 |
| Package volume | 16600 cm³ |
| Certification | TCO Certified, CB, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH |
| Thin Client | |
| Processor architecture | ARM Cortex-A53+Cortex-A73 |
