Vivolink VLMC3770S signage display mount 177.8 cm (70") Black
Vivolink VLMC3770S, 50 kg, 94 cm (37"), 177.8 cm (70"), 200 x 200 mm, 600 x 400 mm, 778 - 1128 mm
Availability:: Arriving soon
The Vivolink VLMC3770S is a full-motion ceiling mount designed to offer the ultimate in versatility and universal compatibility. Telescopic height adjustable Ceiling Mount with the ability to turn 360 degrees and tilt 25 degrees.Tilting ceiling plate for flat and sloping ceiling application. It allows displays to tilt down and swivel around the pole without tools. Includes VESA plate to accommodate virtually any 37" – 70" LCD TV or monitor up to 50kg/110lbs. Fast assembly and very low installation time. The cables can run through the pole for an elegant and minimalistic finish. The adjusting is done easy and sits tight so it is not sensitive to vibrations etc. Adjustable in height, from ceiling to center of screen: 560mm to 910mm. Applications: Air ports, shops, hotels etc.
| Mounting | |
|---|---|
| Maximum weight capacity | 50 kg |
| Minimum screen size | 37 " |
| Number of displays supported | 1 |
| Maximum screen size | 70 " |
| Mounting type | Ceiling |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 600 x 400 mm |
| Panel mounting interface | 200 x 200 mm |
| Ergonomics | |
| Height adjustment | Y |
| Height adjustment type | Manual |
| Height adjustment range | 778 - 1128 mm |
| Tilt angle range | -25 - 0 ° |
| Swivel angle | 360 ° |
| Swivel angle range | -180 - 180 ° |
| Angle of rotation | 360 ° |
| Telescopic | Y |
| Adjustable | Y |
| Cable management | Y |
| Rotating | Y |
| Tilt adjustment | Y |
| Design | |
| Product colour | Black |
| Housing material | Steel |
| Weight & dimensions | |
| Width | 680 mm |
| Depth | 435 mm |
| Height | 1128 mm |
| Weight | 5600 g |
| Packaging data | |
| Package width | 305 mm |
| Package depth | 145 mm |
| Package height | 760 mm |
| Package weight | 6300 g |
| Package volume | 30000 cm³ |
| Packaging content | |
| Manual | Y |
| User guide | Y |
| Mounting kit | Y |
| Screws included | Y |
| Wrench included | Y |
| Technical details | |
| Easy to install | Y |
| VESA mount included | Y |
| Compliance certificates | RoHS |
| Other features | |
| VESA mounting | Y |
| Logistics data | |
| Harmonized System (HS) code | 85299097 |
