NETGEAR M4350-24X4V Managed L3 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Black
NETGEAR M4350-24X4V, Managed, L3, 10G Ethernet (100/1000/10000), Power over Ethernet (PoE), Rack mounting, 1U
Availability: Arriving Soon
POWER AND THROUGHPUTEdge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.Groundbreaking AV GUIA simplified user interface makes it easy to assign configuration profiles to each port.Multicast in an InstantNETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.Sleek, Quiet DesignLess fan noise, and mounting ears included for rack mounting.Automatic ConfigurationAuto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.FAST, EASY CONFIGURATION FOR AV PROSA streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.FOCUS ON THE EVENT NOT FAN NOISEMost models have quiet mode which greatly reduces fan noise.DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOXWith built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| ARP inspection | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| 10G Ethernet (copper) ports quantity | 24 |
| SFP28 ports quantity | 4 |
| Power connector | AC-in jack |
| Network | |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1Qav,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ak,IEEE 802.3bz,IEEE 802.3u |
| 10G support | Y |
| Full duplex | Y |
| Policy-based routing | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Spanning tree protocol | Y |
| 6to4 tunnel | Y |
| IPv4 routes | 512 |
| IPv6 routes | 256 |
| VLAN support | Y |
| Virtual LAN features | MAC address-based VLAN,Private VLAN,Voice VLAN |
| Number of VLANs | 4093 |
| Data transmission | |
| Switching capacity | 680 |
| Throughput | 505.92 |
| MAC address table | 16000 |
| Store-and-forward | Y |
| Latency (1 Gbps) | 2.43 |
| Latency (10 Gbps) | 2.2 |
| Jumbo frames support | Y |
| Jumbo frames | 12000 |
| Packet buffer memory | 32 |
| Security | |
| DHCP features | DHCP Option 150,DHCP Option 66,DHCP Option 67,DHCP relay,DHCP server,DHCP snooping |
| Access Control List (ACL) | Y |
| Access Control List (ACL) egress | 1023 |
| Access Control List (ACL) ingress | 511 |
| IGMP snooping | Y |
| IGMP proxy | Y |
| MAC address filtering | Y |
| Static port security | Y |
| Loop protection | Y |
| BPDU filtering/protection | Y |
| Authentication | Guest VLAN,MAC-based authentication |
| Root protection | Y |
| Password protection | Y |
| DoS attack prevention | Y |
| Authentication type | RADIUS,TACACS+ |
| Queue scheduling algorithms | Strict Priority Queue (SPQ),Weighted random early detection (WRED) |
| Multicast features | |
| Multicast support | Y |
| Multicast Listener Discovery (MLD) snooping | Y |
| Protocols | |
| Management protocols | SNMP V1, V2, V3 |
| GARP VLAN Registration Protocol (GVRP) | Y |
| Routing protocols | OSPF,OSPFv2,OSPFv3,RIP,RIP-1,RIP-2 |
| Design | |
| Rack mounting | Y |
| Stackable | Y |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Y |
| Airflow direction | Front-to-back airflow |
| Performance | |
| Built-in processor | Y |
| Processor model | ARM Cortex-A57 |
| Processor frequency | 1800 |
| Memory type | DDR4-SDRAM |
| Internal memory | 2048 |
| Flash memory | 512 |
| sFlow | Y |
| Power | |
| Power source | AC |
| Power supply included | Y |
| Power consumption (typical) | 119.4 |
| Power consumption (max) | 750.1 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Power over Ethernet (PoE) power per port | 30 |
| Total Power over Ethernet (PoE) budget | 720 |
| Other features | |
| Power supply | 880 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 |
| Storage temperature (T-T) | -20 - 70 |
| Operating relative humidity (H-H) | 0 - 90 |
| Storage relative humidity (H-H) | 0 - 95 |
| Operating altitude | 0 - 3000 |
| Non-operating altitude | 0 - 3000 |
| Weight & dimensions | |
| Width | 440 |
| Depth | 400 |
| Height | 43.2 |
| Weight | 6580 |
| Packaging content | |
| Cables included | AC,USB Type-C |
| Quick start guide | Y |
| Rack mount kit | Y |
| Packaging data | |
| Included power plug types | EU,UK,NA |
| Sustainability | |
| Sustainability compliance | Y |
| Certificates | |
| Compliance certificates | BSMI,CCC,CE,Federal Communications Commission (FCC),Low Voltage Directive (LVD) |
