ASUS PRIME H510M-A R2.0 Intel H510 LGA 1200 (Socket H5) micro ATX
(0 review)Add your review
€78,58

ASUS PRIME H510M-A R2.0, Intel, LGA 1200 (Socket H5), Intel® Celeron®, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™..., LGA 1200 (Socket H5), DDR4-SDRAM, 64 GB

Availability:: Arriving soon
EAN:4711387234891Categories:Hardware Components

H510M-A R2.0ASUS Prime series motherboards are expertly engineered to unleash the full potential of 11th and 10th Generation Intel® processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME H510M-A R2.0 provides daily users and DIY PC builders a range of performance tuning options via intuitive software and firmware features.FLEXIBILITYComprehensive controls form the foundation of the ASUS Prime series. The Prime H510 motherboard packs flexible tools to tune every aspect of your system, enabling performance tweaks to perfectly match the way you work, to maximize productivity.Intelligent ControlASUS Intelligent Control makes your PC smart. Along with taking care of complex tuning and dynamically optimizing essential aspects of your system, it offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans.All-Around Energy EfficiencyWith the Energy Processing Unit (EPU), you'll enjoy system-wide power savings. The EPU automatically optimizes power consumption and maximizes savings with Away mode.COOLINGPrime H510 series is engineered with an array of hybrid fan headers to ensure your rig stays cool and stable under intense workloads.M.2 HeatsinkM.2 heatsink wards off throttling that can occur with M.2 storage during sustained transfers. The heatsink is held in place by captive screws, and these removable captive screws help reduce risk of drops or loss during heatsink removal.PERFORMANCEPrime H510 series is built to handle the additional cores and increased bandwidth of 11th Generation Intel® Core™ processors. ASUS H510 motherboards provide all the fundamentals to boost daily productivity, so your system will be ready for action with stable power, intuitive cooling and flexible transfer options.

Processor
Processor manufacturerIntel
Processor socketLGA 1200 (Socket H5)
Compatible processor seriesIntel Celeron,Intel Pentium Gold,Intel Core i3,Intel Core i5,Intel Core i7,Intel Core i9
Supported processor socketsLGA 1200 (Socket H5)
Memory
Supported memory typesDDR4-SDRAM
Number of memory slots2
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilitynon-ECC
Supported memory clock speeds2133,2400,2666,2800,2933,3000,3200
Supported memory clock speed (max)3200
Maximum internal memory64
Unbuffered memoryY
Storage controllers
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2,SATA III
Number of HDDs supported4
Number of storage drives supported5
Graphics
Parallel processing technology supportNot supported
Internal I/O
USB 2.0 connectors3
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Number of SATA III connectors4
S/PDIF out connectorY
Audio connectorY
Front panel audio connectorY
ATX Power connector (24-pin)Y
CPU fan connectorY
Number of chassis fan connectors2
EPS power connector (8-pin)Y
Number of COM connectors1
TPM connectorY
12V power connectorY
RGB LED pin headerY
Rear panel I/O ports
USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Ethernet LAN (RJ-45) ports1
PS/2 ports quantity2
VGA (D-Sub) ports quantity1
HDMI ports quantity1
DisplayPorts quantity1
Headphone outputs1
Line-inY
Microphone inY
Network
Ethernet LANY
Ethernet interface typeGigabit Ethernet
Wi-FiN
Features
Motherboard chipsetIntel H510
Audio output channels7.1
Component forPC
Motherboard form factorMicro ATX
Motherboard chipset familyIntel
Windows operating systems supportedWindows 10 x64
Expansion slots
PCI Express x1 (Gen 3.x) slots2
Number of M.2 (M) slots1
BIOS
BIOS typeUEFI AMI
BIOS memory size128
Packaging data
Package width260
Package depth270
Package height51.5
Package weight1030
Weight & dimensions
Width226
Depth211
Packaging content
Cables includedSATA
