Lenovo 1754D1X KVM switch Rack mounting Black
€1342,26
Lenovo 1754D1X, 1600 x 1200 pixels, Ethernet LAN, Rack mounting, 18 W, 1U, Black
Availability:: Arriving soon
The IBM GCM16 Global Console Manager includes the following items:- 16-port console switch- Mounting hardware for EIA space for rack sidewall compartment- One 1U filler panel- Two C13/C14 rack power cables- RJ45-DB9F DCE adapter for use with Setup port- RJ45-DB9M DTE adapter for use with Modem port- 16 terminators for daisy-chaining configurations- Installation publications and warranty
| Ports & interfaces | |
|---|---|
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | VGA |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Audio connections | N |
| Console port | RJ-45 |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN (RJ-45) ports | 16 |
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Performance | |
| Maximum resolution | 1600 x 1200 pixels |
| Design | |
| Rack mounting | Y |
| Rack capacity | 1U |
| Product colour | Black |
| Display | |
| Built-in display | N |
| Power | |
| Input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 18 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Storage relative humidity (H-H) | 5 - 95 % |
| Weight & dimensions | |
| Width | 431.8 mm |
| Depth | 324 mm |
| Height | 43.7 mm |
| Weight | 3200 g |
| Logistics data | |
| Harmonized System (HS) code | 85176200 |
