Lanview MO-OSX010000 network transceiver module Fiber optic 10000 Mbit/s SFP+ 1310 nm
Lanview MO-OSX010000, Fiber optic, 10000 Mbit/s, SFP+, LC, 9/125,9/128 µm, 10000 m
Availability: Arriving Soon
EET has expanded the offerings to support a wide range of optical transceivers ranging from GBIC to XFP. All of the products comply with MSA and environmental standards. Why 3rd party transceivers? OEM´s such as HP, Cisco, 3Com (HP) and many others don´t make any transceivers themselves but relabel standard products and add huge margins. We have decided to give our customers a choice. Buy original or save up to 60 % and get high quality products with: - 10 Year warranty- 100% Compatability- Availability from our extensive stock- High Quality - all products are tested- Huge savings on quality alternatives to “originals” Buying MicroOptics Transceivers does not mean your equipment warranty is void.
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 10000 Mbit/s |
| Interface type | SFP+ |
| Single-mode fiber (SMF) supported | Y |
| Multi-mode fiber (MMF) supported | N |
| Fiber optic connector | LC |
| Fiber cable diameters supported (core/cladding) | 9/125,9/128 µm |
| Maximum transfer distance | 10000 m |
| Wavelength | 1310 nm |
| Ethernet interface type | 10 Gigabit Ethernet |
| Fiber ethernet cabling technology | 10GBASE |
| Features | |
| Product colour | Metallic |
| Form factor | SFP+ |
| Plug and Play | Y |
| Easy to install | Y |
| Brand compatibility | Huawei |
| Compatible products | OSX010000 |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | MSA, RoHS |
| Sustainability | |
| Sustainability compliance | Y |
| Operational conditions | |
| Minimum operating temperature | 0 °C |
| Maximum operating temperature | 70 °C |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 85 % |
| Weight & dimensions | |
| Width | 12 mm |
| Depth | 56 mm |
| Height | 8.5 mm |
| Weight | 10 g |
| Packaging data | |
| Package width | 105 mm |
| Package depth | 69 mm |
| Package height | 23 mm |
| Package weight | 30 g |
| Logistics data | |
| Warranty period | 3 year(s) |
