D-Link DGS-1100-24PV2 Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
(0 review)Add your review
€284,79

D-Link DGS-1100-24PV2, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting

Availability: Arriving Soon
EAN:0790069467837Categories:NetworkingTags:

Powerful Switching for your BusinessThe DGS-1100 Series is a range of powerful switches that offer a lot of bang for your buck. They are great for busy SMBs who expect a lot of their network, including support for surveillance and VoIP. They are packed with traffic management & optimization features that keep your network congestion free. Meanwhile, management tools are flexible and intuitive, making your life easier.Gigabit Ethernet SpeedsTake your Ethernet speeds to the next level with Gigabit ConnectivityCutting Edge Green TechnologyInnovative D-Link Green power saving features keep your budget in checkManage Anywhere, AnytimeRemote setup & management is easy, and can be done from anywhere.Easy to Use & Easy to InstallD-Link Network Assistant Utility (DNA) can quickly discover and do initial setup for D-Link Networking devices such as the DGS-1100 Series, which greatly improves efficiency for solution deployment.VLANs: Stronger Security & Better Traffic ManagementRelatively easy to set up, VLANs can be a big boon for your network. They can isolate sensitive areas of your network, keeping them safe from those with malicious intent, or keeping bandwidth open for latency-sensitive traffic such as VoIP.For VoiceIf VoIP calls make up a large slice of your network usage, separating them onto their own VLAN can ensure they get the bandwidth they need for smooth conversations without lag or jitters.For SurveillanceIf you have surveillance cameras and devices attached to your network, putting them onto their own VLAN keeps surveillance footage running seamlessly. At the same time, it can help prevent a variety of malicious attacks by restricting access to different network areas.Green TechnologyD-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. Most of the models in the series utilize a fanless design, for silent and energy-efficient operation. All are IEEE 802.3az-compliant and feature Link Status detection and Time-Based PoE.

Management features
Switch typeManaged
Switch layerL2
Quality of Service (QoS) supportY
Web-based managementY
System event logY
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Network
Networking standardsIEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G supportN
Copper ethernet cabling technology10BASE-T,10BASE-TX,1000BASE-T
Port mirroringY
Full duplexY
Flow control supportY
Link aggregationY
Broadcast storm controlY
Rate limitingY
Auto MDI/MDI-XY
Spanning tree protocolY
Head-of-line (HOL) blockingY
Auto-negotiationY
VLAN supportY
Virtual LAN featuresPort-based VLAN,Voice VLAN
Number of VLANs128
Data transmission
Switching capacity48
Forwarding rate35.71
MAC address table8000
Store-and-forwardY
Number of queues4
Jumbo frames supportY
Jumbo frames9216
Packet buffer memory4.1
Security
DHCP featuresDHCP client
IGMP snoopingY
Security algorithmsSNMP,SSL/TLS
Queue scheduling algorithmsSPQ,Weighted Round Robin (WRR)
Multicast features
Multicast supportY
Design
Rack mountingY
Product colourBlack
LED indicatorsY
Performance
Built-in processorY
Processor frequency125
Memory typeDRAM
Flash memory16
Noise level0
FanlessY
Mean time between failures (MTBF)255003
Power
AC input voltage100 - 240
Power consumption (max)19.5
Power over Ethernet (PoE)
Power over Ethernet (PoE)Y
Power over Ethernet plus (PoE+) ports quantity12
Power over Ethernet (PoE) power per port30
Total Power over Ethernet (PoE) budget100
Operational conditions
Operating temperature (T-T)-5 - 50
Storage temperature (T-T)-40 - 70
Operating relative humidity (H-H)0 - 95
Storage relative humidity (H-H)0 - 95
Operating altitude0 - 2000
Heat dissipation107.5
Weight & dimensions
Width280
Depth230
Height44
Weight2200
Certificates
CertificationEMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC cUL, CE LVD, CB, BSMI, CCC
