DELL 405-AAMY RAID controller PCI Express 3.0 12 Gbit/s
DELL 405-AAMY, SAS, Serial ATA III, PCI Express, 0, 1, 5, 6, 10, 50, 60, 12 Gbit/s, 2048 MB, DDR3
Availability:: Arriving soon
The PERC H730P+ RAID Controller from Dell offers reliability and performance in addition to providing management with the tolerant disk subsystem failures. This RAID controller offers expandable 2 GB storage capacity to improve the performance of your server systems. The double module channel provides high-speed connectivity. This product has been tested and validated on Dell systems to ensure compatibility with your computer. It is supported by Dell Technical Support when used with a Dell system. This product is compatible with the following systems:PowerEdge R740PowerEdge R740XDPowerEdge R440PowerEdge T640PowerEdge T440PowerEdge R540
| Ports & interfaces | |
|---|---|
| Supported storage drive interfaces | SAS,Serial ATA III |
| Host interface | PCI Express |
| PCI Express slots version | 3.0 |
| Internal mini-SAS ports | 2 |
| Performance | |
| RAID levels | 0,1,5,6,10,50,60 |
| RAID Level Migration | Y |
| Data transfer rate | 12 Gbit/s |
| SSD support | Y |
| Internal memory | 2048 MB |
| Internal memory type | DDR3 |
| Memory clock speed | 1866 MHz |
| S.M.A.R.T. support | Y |
| Number of devices supported | 255 |
| Online Capacity Expansion | Y |
| Compatible products | - PowerEdge R440 - PowerEdge R540 - PowerEdge R940xa - PowerEdge R940 - PowerEdge T140 - PowerEdge R840 - PowerEdge R340 - PowerEdge R7425 - PowerEdge R740 - PowerEdge R740XD - PowerEdge T640 - PowerEdge R240 - PowerEdge R640 - PowerEdge T440 - PowerEdge T340 |
| Processor | |
| Built-in processor | Y |
| Power | |
| Voltage | 3.3 V |
| Technical details | |
| Product name | PERC H730 |
| System requirements | |
| Windows operating systems supported | Y |
| Mac operating systems supported | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 °C |
| Weight & dimensions | |
| Width | 167.6 mm |
| Height | 64.4 mm |
