MSI MAG A550BN UK PSU '550W, 80 Plus Bronze certified, 12V Single-Rail, DC-to-DC Circuit, 120mm Fan, Non-Modular, Sleeved Cables, ATX Power Supply Unit, UK Powercord, Black'
MSI MAG A550BN UK PSU '550W, 80 Plus Bronze certified, 12V Single-Rail, DC-to-DC Circuit, 120mm Fan, Non-Modular, Sleeved Cables, ATX Power Supply Unit, UK Powercord, Black', 550 W, 100 - 240 V, 50 - 60 Hz, 8 A, 4 A, Active
Availability: Arriving Soon
MAG A550BN provides players with a safe, reliable, and efficient entry-level power supply option. Its core features include 80 PLUS Bronze certification, DC to DC circuit design, 12V single rail, active PFC, and low-noise fan. The MAG A550BN will be one of the best choices for players who are just getting started with looking into DIY computers. After installation, gamers can immediately enjoy a reliable performance experience without additional settings.80 PLUS BRONZE CERTIFIEDThe efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 PLUS BRONZE certification promises lower energy consumption and higher efficiency.120MM LOW NOISE FANThe fan’s sleeve bearing reduces the noise generated while maintaining excellent heat dissipation.DC TO DC CIRCUIT DESIGNAdopted DC-DC circuit design reduces the instability of output voltage, and ads stability to the supply of power.COMPREHENSIVE CIRCUIT PROTECTIONSupports OCP, OVP, SCP, OPP, OTP protectionmechanisms and provides comprehensive protection.5-YEAR LIMITED WARRANTYThe MAG A550BN is proudly backed by a 5-year limited warranty, guaranteeing long term reliable operation.
| Power | |
|---|---|
| Total power | 550 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Maximum input current (@110V) | 8 |
| Maximum input current (@220V) | 4 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 110 |
| Combined power (+12V) | 546 |
| Combined power (+5V) | 110 |
| Combined power (-12V) | 3.6 |
| Combined power (+5Vsb) | 12.5 |
| Max output current (+3.3V) | 20 |
| Max output current (+12V) | 45.5 |
| Max output current (+5V) | 20 |
| Max output current (-12V) | 0.3 |
| Max output current (+5Vsb) | 2.5 |
| Efficiency | 85 |
| Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 600 |
| Number of SATA power connectors | 5 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| EPS power connector (8-pin) | N |
| EPS power connector (4+4 pin) | Y |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU power connector (4+4 pin) | Y |
| ATX Power connector (24-pin) | N |
| ATX power connector (20+4 pin) | N |
| Floppy drive power connector | 1 |
| Floppy disk drive connector | Y |
| Cabling type | Non-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Bronze |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 120 |
| Number of fans | 1 |
| On/off switch | Y |
| Weight & dimensions | |
| Width | 150 |
| Depth | 140 |
| Height | 86 |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
