D-Link DMS-3130-30PS network switch Managed L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Black
D-Link DMS-3130-30PS, Managed, L3, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting, 1U
Availability: Arriving Soon
The DMS-3130 Series is a range of Layer 3 Stackable Managed Switches designed to connect end-users in a secure enterprise or metro Ethernet access network. These switches support both multicasting and enhanced security, making them an ideal multi-Gigabit access layer solution. The DMS-3130 Series has PoE and non-PoE models equipped with multi-Gigabit Ethernet and SFP network connection options. The DMS-3130 Series includes models equipped with multiGigabit Ethernet and SFP28 network connection options. The DMS-3130-30PS provides 16 PoE ports using 802.3af and 802.3at, and 8 ports using 802.3bt 60W PoE standards with default power budgets of 740 watts and the potential to be expanded to 960 watts with dual power supplies. Each model boasts 2 10GBASE-T ports and 4 10/25G SFP28 ports to provide versatility and speed. This series is also equipped with a USB 2.0 port, allowing users to boot images and upload configuration files directly from, as well as conveniently save syslog files to a USB 2.0 storage device.
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 26 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Console port | RJ-45 |
| SFP28 ports quantity | 4 |
| USB 2.0 ports quantity | 1 |
| Network | |
| Networking standards | IEEE 802.1AX,IEEE 802.1D,IEEE 802.1p,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt,IEEE 802.3x |
| 10G support | Y |
| Port mirroring | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Head-of-line (HOL) blocking | Y |
| VLAN support | Y |
| Virtual LAN features | MAC address-based VLAN,Multicast VLAN,Port-based VLAN,Private VLAN,Voice VLAN |
| Number of VLANs | 4000 |
| Data transmission | |
| Switching capacity | 400 |
| Forwarding rate | 298 |
| MAC address table | 32768 |
| Number of queues | 8 |
| Jumbo frames support | Y |
| Packet buffer memory | 4 |
| Security | |
| DHCP features | DHCP guarding,DHCP server,DHCP snooping |
| Access Control List (ACL) | Y |
| Access Control List (ACL) egress | 1024 |
| Access Control List (ACL) ingress | 3072 |
| IGMP snooping | Y |
| SSH/SSL support | Y |
| Loop protection | Y |
| Authentication | Guest VLAN,MAC-based authentication,Port-based authentication,Web-based authentication |
| Authentication type | IEEE 802.1x,RADIUS,TACACS+ |
| Multicast features | |
| Multicast support | Y |
| Protocols | |
| GARP VLAN Registration Protocol (GVRP) | Y |
| Design | |
| Rack mounting | Y |
| Stackable | Y |
| Form factor | 1U |
| Product colour | Black |
| Number of fans | 2 |
| Performance | |
| Physical stacking (units) | 9 |
| Virtual stacking (units) | 32 |
| Mean time between failures (MTBF) | 277222.63 |
| Power | |
| Power source | AC/DC |
| Power supply included | Y |
| Redundant power supply (RPS) support | Y |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Power consumption (max) | 1211.5 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 740 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 |
| Storage temperature (T-T) | -40 - 70 |
| Operating relative humidity (H-H) | 10 - 90 |
| Storage relative humidity (H-H) | 5 - 90 |
| Heat dissipation | 4137.73 |
| Weight & dimensions | |
| Width | 440 |
| Depth | 470 |
| Height | 44 |
| Weight | 6540 |
| Certificates | |
| Certification | FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI |
